Connections and Operation:
Before installation, please make sure all devices you wish to connect have been turned off.
• Connect the HDMI input source into the HDMI switcher. (Input cables are optional)
• Connect the HDMI output device into the switcher.
• Insert the DC side of 5 V power supply into the switcher and then connect the AC side of the
power supply into the wall outlet.
• Power on all input and output devices.
HDMI DVD
HDMI DVD
HDMI DVD
HDMI DVD
Warning: If a DVI device does not appear to work, make certain that the device is HDCP
compliant. A non-HDCP compliant DVI device will not work with a signal that has HDCP
encoding present
HDMI Switch
4
HDMI Monitor
