Installation Instructions - Bluewheel HOVOKART HK200 Benutzerhandbuch

Attach the two footplate attachments to the sides of the main frame.
Main frame - Washer (# 7) - Front frame - Washer (# 7) - Spring washer (# 8) - Locking nut M10 (# 9)
Attach the seat to the main frame.
M8 Screw (# 6) - M8 Locknut (# 5)
Place the Hovocart frame on the center of the
Hoverboard.
Pull the straps from the opposite side through the eyelets and
secure the Velcro.
10

2. INSTALLATION INSTRUCTIONS

Attach the front frame to the main frame.
Fastener (# 10)
Loosen the nuts of the rear retaining brackets and adjust
them to the width of the treads (then tighten).
The Hovocart is now ready for ride.
