INPUT SPECIFICATIONS
Input A
Input Impedance:
Frequency Range:
Sensitivity:
Input B
Input Impedance:
Frequency Range:
Sensitivity:
Maximum Input Voltage
Input A and Input B:
Note that the inputs will not be damaged if subjected to an accidental short-term connection to a
50/60Hz line voltage not exceeding 250V rms.
POWER REQUIREMENTS
Battery Type:
Battery Life:
Low Battery Indicator:
GENERAL
Display:
Operating Range:
Storage Range:
Environmental:
Size:
Weight:
Electrical Safety:
EMC:
Telemeter Electronic GmbH | Joseph-Gaensler-Str. 10 | Phone +49 906 70693-0 | Fax +49 906 70693-50 | www.telemeter.info
1MΩ//20pF (AC coupled)
<3Hz to >125MHz
Sinewave - 15mVrms 10Hz to 125MHz
50Ω nominal (AC coupled)
<80MHz to >3GHz
Sinewave - 12mVrms 80MHz to 2GHz, 25mVrms to 2.5GHz,
50mVrms to 3GHz
30Vdc; 30V rms 50/60Hz with respect to ground
to 1Vrms above 1MHz
9V PP3 alkaline
Typically 20 hours
'Bat' shows in display when approximately 10% of battery life
remains.
8½ digit LCD,
11.5mm high (0.45");
15 annunciators show measurement units, input, mode and
time.
+5°C to +40°C, 20% to 80% RH
20°C to +60°C
–
Indoor use at altitudes up to 2000m Pollution Degree 2
81mm x 178mm x 30mm (WxLxD)
190gms excluding battery
Complies with EN61010-1
Complies with EN61326
, reducing
