Jysk FALSLEV Montageanleitung Seite 6

C1 x 1
570x150x360mm
C5 x 1
830x95x500mm
3690094
C1
C4
C7
C8
C7
C8
C2 x 1
560x170x500mm
C6 x 1
560x660x160mm
C2
C3
C6
C3 x 1
570x670x150mm
C7 x 4
Φ48x2mm
6/9
C5
C7
C8
C7
C8
C4 x 1
830x95x500mm
C8 x 4
Φ60x120mm
2015.06.24
