AquaMic Foam Spacer (CI-7517) AquaMic UHP Magnet (CI-7511) Bottom Cover Patch Color Cap/Magnet Removal Tool (CI-7513) (CI-7514)
Seite 3
Warnings • The AquaMic contains small parts that could cause choking if swallowed. • Seek medical attention if any headpiece magnets are swallowed. • Do not use the AquaMic if the housing is broken or cracked. • Do not use broken, frayed, or cracked cables. •...
Seite 4
Adding Magnets If needed, additional UHP magnets* may be added one at a time within the AquaMic (Figure 1). If AquaMic retention is inadequate with four internal magnets, the Bottom Cover Patch** may be removed, and one thin magnet*** (CI-7518, packaged separately) may be added to the external well (Figure 2).
Seite 5
The Neptune sound processor and AquaMic carry a rating of IP68. This rating indicates that the Neptune system when using these parts is protected against the following conditions: • Complete protection against dust penetration • Failure due to continuous immersion in water up to 3 meters (9 ft.
Seite 6
Place in Zephyr by Dry & Store® or similar desiccant device to dry completely • Unaided listeners may periodically assess AquaMic sound qual- ity using the built-in Neptune Connect microphone listening mode. For instructions, consult your Neptune User Guide. Cable* To avoid damage to the cable when removing from the AquaMic, grasp only by the connector.
Seite 7
Do not remove or replace the cable from the sound processor or AquaMic while under water. If the cable becomes accidentally detached during water use, remove the sound processor from the water and shake any excess water from the processor and cable connectors prior to re-connecting the cable.
Seite 9
Replacing the Bottom Cover Patch Peel the paper backing from the patch and press into place, adhesive side down.
Seite 10
Cleaning • Use a soft cloth to clean. Do not use solvents other than water. Recommended operating temperature: 0˚C (32˚F) - 45˚C (115˚ F) Labeling symbols and their meanings: European Community Mark of Conformity. Authorized to affix the CE Mark in 2011 Model number Warning Serial number...
Seite 11
Dispose of in accordance with applicable national and local regulations Store at temperatures between -20˚C (-4˚F) and +55˚C (131˚F) Suitable for atmospheric range between 69.6kPa 130 kPa and 130kPa, which is equivalent to 3000m above sea level to 380m below sea level. 69.6 kPa Suitable for exposure to relative humidity between 0-95%...
Seite 12
Implant Type HiRes HiRes 90K Advantage Naída CI Q90 ✓ ✓ ✓ Naída CI Q70 ✓ ✓ ✓ Naída CI Q30 ✓ ✓ ✓ Neptune ✓ ✓ ✓ Harmony ✓ ✓ ✓ ✓ Auria ✓ ✓ ✓ Platinum Sound ✓ ✓...
Seite 15
Implant Type C1 CII HiRes 90K HiRes 90K Advantage Concave ✓ ✓ ✓ ✓ ✓ ✓ AquaMic ✓ ✓ ✓ HR90K Auria ✓ ✓ Headpiece Platinum ✓ ✓ ✓ ✓ Headpiece Naída CI Q90, Naída CI Q30, and AquaCase are only available in markets where regulatory approval has been received and the product has been made commercially available.
Seite 16
AquaMic Espaceur en mousse (CI-7517) AquaMic Aimant d'AU (CI-7511) Capuchon interne Cache coloré/Outil de retrait pour aimant (CI-7513) (CI-7514)
Seite 17
Avertissements • L'AquaMic contient de petites pièces présentant un risque de suffocation si elles sont avalées. • Demandez un avis médical en cas d'ingestion d'aimants d'antenne. • L'AquaMic ne doit pas être utilisée si le cache est cassé ou fendu. •...
Seite 18
Ajout d'aimants En cas de besoin, des aimants supplémentaires* peuvent être ajoutés un par un à l'intérieur de l'AquaMic (Figure 1). Si la fixation de l'antenne AquaMic n'est pas suffisante avec quatre aimants internes, la pastille de protection interne** peut être retirée, et un seul aimant fin*** (CI-7518, conditionné...
Seite 19
L'indice IP du processeur de son Neptune et de l'antenne AquaMic est IP68. Cela signifie que lorsque ces éléments sont utilisés sur le système Neptune, l'ensemble est protégé contre : • Toute pénétration de poussière (protection totale) • Toute défaillance due à l'immersion continue dans de l'eau jusqu'à...
Seite 20
AquaMic à l'aide du mode de contrôle du microphone intégré au module de contrôle/connectique Neptune. Pour de plus amples instructions, consultez le mode d'emploi du système Neptune. Cordon* Pour éviter d'endommager le cordon lors de son retrait de l'AquaMic, il doit être tenu par le connecteur uniquement.
Seite 21
Évitez de retirer ou remplacer le cordon du processeur de son ou de l'AquaMic sous l'eau. Si le cordon se détache accidentellement sous l'eau, sortez le processeur de son de l'eau et agitez-le pour enlever l'excès d'eau du processeur de son et des connecteurs de cordon avant de reconnecter les cordons.
Seite 23
Remplacement de la pastille de protection centrale Décollez le papier de l'arrière de la pastille de protection centrale et appliquez à l'emplacement approprié en appuyant dessus avec l'adhésif positionné contre l'antenne.
Seite 24
Nettoyage • Utiliser un chiffon doux pour le nettoyage. Évitez l'utilisation de tout solvant autre que l'eau. Température de fonctionnement recommandée : 0 ˚C (32 ˚F) à 45 ˚C (115 ˚F) Symboles d'étiquetage et leur signification : Marquage de conformité de la Communauté Européenne. Autorisé...
Seite 25
Mettre au rebut selon les règlements nationaux et locaux en vigueur À stocker à une température comprise entre -20 ˚C (-4 ˚F) et +55 ˚C (131 ˚F) Peut être utilisé à une pression atmosphérique 130 kPa comprise entre 69,6 kPa et 130 kPa, soit entre 3 000 m au-dessus du niveau de la mer et 380 m 69.6 kPa au-dessous du niveau de la mer.
Seite 26
HiRes HiRes 90K Advantage Naída CI Q90 ✓ ✓ ✓ Naída CI Q70 ✓ ✓ ✓ Naída CI Q30 ✓ ✓ ✓ Neptune ✓ ✓ ✓ Harmony ✓ ✓ ✓ ✓ Auria ✓ ✓ ✓ Processeur de Son ✓ ✓...
Seite 27
Type d'implant HiRes HiRes 90K Advantage SClin2000 ✓ ✓ SoundWave 1.4 (ou version ✓ ✓ antérieure) SoundWave 2.0 ✓ ✓ ✓ SoundWave 2.1 ✓ ✓ ✓ ✓ SoundWave 2.2 ✓ ✓ ✓ ✓ SoundWave 2.3 ✓ ✓ ✓ ✓ Seulement avec Harmony...
Seite 28
Type de processeur Naída Neptune Harmony Auria AU concave ✓ ✓ ✓ ✓ ✓ Antenne Universelle ✓ ✓ ✓ ✓ ✓ (AU) AquaMic ✓ ✓ Antenne Auria ✓ ✓ HR90K Antenne ✓ ✓ ✓ Platinum Nécessite le boîtier AquaCase™...
Seite 29
Type d'implant C1 CII HiRes 90K HiRes 90K Advantage AU concave ✓ ✓ Antenne Universelle ✓ ✓ ✓ ✓ (AU) AquaMic ✓ ✓ ✓ Antenne Auria ✓ ✓ HR90K Antenne ✓ ✓ ✓ ✓ Platinum Naída CI Q90, Naída CI Q30, et AquaCase sont disponibles uniquement sur les marchés bénéficiant d'une approbation réglementaire et où...
Seite 30
AquaMic Schaumstoffeinlage (CI-7517) AquaMic UHP-Magnet (CI-7511) Untere Abdeckung (CI-7513) Farbkappe/Werkzeug für Magnetwechsel (CI-7514)
Seite 31
Warnhinweise • Der AquaMic enthält Kleinteile, die verschluckt werden können und eine Erstickungsgefahr darstellen. • Suchen Sie einen Arzt auf, wenn ein Überträgermagnet verschluckt wurde. • Verwenden Sie den AquaMic nicht, wenn das Gehäuse beschädigt oder gerissen ist. • Verwenden Sie keine beschädigten, zerfaserten oder gebrochenen Kabel. •...
Seite 32
Hinzufügen von Magneten Bei Bedarf können zusätzliche UHP-Magneten* einzeln in das AquaMic eingefügt werden (Abbildung 1). Wenn die vier internen Magneten des AquaMic nicht für einen sicheren Halt ausreichen, entfernen Sie die untere Abdeckung** und fügen Sie einen dünnen Magneten*** (CI-7518, separat verpackt) im äußeren Magnetfach ein (Abbildung 2).
Der Neptune Soundprozessor und der AquaMic haben die IP- Klassifizierung IP68. Die Schutzklasse zeigt an, dass das Neptune System bei der Verwendung dieser Komponenten gegen Folgendes geschützt ist: • Vollständiger Schutz gegen das Eindringen von Staub • Defekt nach 30 Minuten ununterbrochenem Eintauchen in bis zu 3 Meter tiefem Wasser.
Seite 34
Trockengerät legen • Normalhörende Personen können die Klangqualität des AquaMic regelmäßig mithilfe des Hörmodus des integrierten Neptune Connect Mikrofons überprüfen. Weitere Hinweise dazu finden Sie im Neptune Benutzerhandbuch. Kabel* Ziehen Sie das Kabel immer am Stecker aus dem AquaMic, um Beschädigungen zu vermeiden.
Seite 35
Entfernen oder ersetzen Sie das Kabel des Soundprozessors oder des AquaMic nie unter Wasser. Wenn das Kabel sich im Wasser unbeabsichtigt löst, nehmen Sie den Soundprozessor aus dem Wasser und schütteln das überschüssige Wasser aus dem Prozessor und den Kabelanschlüssen, bevor Sie das Kabel wieder anschließen. Aufsetzen der Farbkappe* Wechseln Sie die Farbkappe...
Seite 37
Ersetzen der unteren Abdeckung Ziehen Sie die Schutzfolie von der unteren Abdeckung ab und bringen Sie sie mit der Klebefläche nach unten an.
Seite 38
Reinigen • Zur Reinigung ein weiches Tuch benutzen. Keine anderen Lösungs- mittel als Wasser verwenden. Empfohlene Betriebstemperatur: 0˚C (32˚F) – 45˚C (115˚ F) Etikettensymbole und ihre Bedeutung: EU-Prüfzeichen. Anbringung des CE-Zeichens 2011 genehmigt. Modellnummer Warnhinweis Serien-Nummer Herstellungsdatum XXXX-XX-XX Hersteller Schutzart: B siehe Gebrauchsanweisung...
Seite 39
Halten Sie sich beim Entsorgen an die vor Ort geltenden gesetzlichen Vorschriften. Aufbewahrung bei -20°C (-4˚F) bis +55°C (131˚F) Geeignet für atmosphärischen Bereich zwischen 130 kPa 69,6 kPa und 130 kPa (3000m über dem Meeresspiegel bis 380m unter dem Meeresspiegel). 69.6 kPa Geeignet für relative Luftfeuchtigkeiten zwischen 0 und 95 %.
Seite 43
Implantattyp C1 CII HiRes 90K HiRes 90K Advantage Konkaver ✓ ✓ Universal- Überträger ✓ ✓ ✓ ✓ (UHP) AquaMic ✓ ✓ ✓ HR90K Auria ✓ ✓ Überträger Platinum ✓ ✓ ✓ ✓ Überträger Naída CI Q90, Naída CI Q30 und AquaCase sind nur in Ländern erhältlich, in denen sie zugelassen sind und im Handel angeboten werden.
Seite 44
AquaMic מרווח מספוג )CI-7517( AquaMic UHP-מגנט ל )CI-7511( טלאי כיסוי תחתון כיסוי צבעוני/כלי להסרת מגנטים )CI-7513( )CI-7514(...
Seite 45
אזהרות . מכיל חלקים קטנים שעלולים לגרום לחנק במקרה של בליעהAquaMic במקרה של בליעת מגנטים של יחידת הראש יש לפנות לקבלת עזרה .רפואית . במידה והתושבת שבורה או סדוקהAquaMic-אין להשתמש ב .אין להשתמש בכבלים חתוכים, שחוקים או סדוקים .על הכיסוי הצבעוני להיות מחובר כאשר יחידת הראש נמצאת בשימוש השתמש...
Seite 46
הוספת מגנטים ,)*( במקרה הצורך, ניתן להוסיף מגנטים נוספים ליחידת ראש אוניברסלית (איור1). אם ארבעה מגנטים אינם מספיקיםAquaMic אחד בכל פעם, לתוך ,)**( במקומו, ניתן להסיר את טלאי הכיסוי התחתוןAquaMic לשמירה על .)2 , ארוז בנפרד) (איורCI-7518( ולהוסיף לתא החיצוני מגנט דק אחד הגברת...
Seite 47
. דירוג זהIP68 הם בעלי דירוגAquaMic- וNeptune מעבד הצלילים של מוגנת מפני התנאיםNeptune מציין שבעת השימוש בחלקים אלה, מערכת :הבאים הגנה מלאה מפני חדירת אבק .תקלה בעקבות טבילה ממושכת במים עד לעומק של 3 מטר למשך 03 דקות...
Seite 48
® .באופן מלא אנשים שאינם נעזרים באמצעי שמיעה יכולים לבצע הערכה של איכות .Neptune Connect במצב האזנה למיקרופון שלAquaMic הקול של .Neptune Connect להוראות יש לעיין במדריך למשתמש של *כבל ., אחזו רק במחברAquaMic-כדי למנוע נזק לכבל בעת הסרתו מ...
Seite 49
אין להסיר או להחליף את הכבל של מעבד הצלילים מתחת למים. אםAquaMic או הכבל מתנתק בעת השימוש במים, יש להוציא את מעבד הצלילים מהמים ולנער את המים העודפים מהמעבד וממחברי .הכבל לפני חיבורו חזרה *מיקום הכיסוי הצבעוני AquaMic החלף את הכיסוי של כל...
Seite 51
החלפת טלאי הכיסוי התחתון קלף את גב הנייר מהטלאי ולחץ אותו .למקומו כשהדבק פונה כלפי מטה...
Seite 52
ניקוי .השתמשו במטלית רכה לניקוי. אין להשתמש בממסים זולת מים :טמפרטורת הפעלה מומלצת 0˚C - 45˚C :סמלים על תוויות והמשמעויות שלהם CE סימן תאימות של האיחוד האירופי. אישור לשימוש בסימן 2011 בשנת אזהרה מספר דגם תאריך ייצור מספר סידורי XXXX-XX-XX B :סוג...
Seite 53
השליכו בהתאם לתקנות המקומיות והארציות המתאימות +55˚C-˚02- לC טמפרטורת אחסון בין , 130 kPa 6.96 לביןkPa מתאים ללחץ אטמוספרי בין 130 kPa שהוא שווה ערך ל- 000,3 מ' מעל גובה פני הים ועד .083 מ' מתחת לגובה פני הים 69.6 kPa 0-95% מתאים...
Seite 58
AquaMic Distanziatore in gomma (CI-7517) AquaMic Magnete UHP (CI-7511) Tassello copertura Strumento di rimozione cappuccio inferiore (CI-7513) colorato/magneti (CI-7514)
Seite 59
Avvertenze • AquaMic contiene piccole parti che, se ingerite, possono essere causa di soffocamento. • In caso di ingerimento di uno o più magneti del sensore, rivolgersi a un medico. • Se l'involucro è rotto o spezzato, non utilizzare l'AquaMic. •...
Seite 60
Aggiunta di magneti Se sono necessari altri magneti UHP* possono essere aggiunti uno alla volta in AquaMic (Figura 1). Se quattro magneti interni non garantiscono una tenuta sufficiente dell'AquaMic, è possibile rimuovere il tassello della copertura inferiore** e aggiungere un magnete sottile*** (CI-7518, in confezione separata) nella rientranza tonda esterna (Figura 2).
Seite 61
Il processore sonoro Neptune e AquaMic hanno un indice di IP68. Tale indice denota che, quando si utilizzano queste parti, il sistema Neptune è protetto dalle seguenti condizioni: • protezione completa da infiltrazioni di polvere • guasti dovuti a immersione continua in acqua a una profondità...
Seite 62
I soggetti con orecchio aperto possono valutare periodicamente la qualità sonora di AquaMic utilizzando la modalità di ascolto del microfono incorporato nell'unità di controllo Neptune. Per istruzioni, consultare il manuale d'uso di Neptune. Cavo* Per evitare danneggiamenti al cavo quando viene rimosso da AquaMic, afferrarlo esclusivamente dal connettore.
Seite 63
Non rimuovere o sostitu- ire il cavo dal processore so- noro o da AquaMic sott'acqua. Se il cavo si stacca acciden- talmente durante l'utilizzo in acqua, rimuovere il processore sonoro dall'acqua e scuotere l'eccesso di acqua dal proces- sore sonoro e dai connettori del cavo prima di riconnettere il cavo. Posizionamento del cappuccio colorato* Sostituire il cappuccio AquaMic...
Seite 65
Sostituzione del tassello della copertura inferiore Staccare il rivestimento dal tassello e inserirlo in posizione con la parte adesiva rivolta verso il basso.
Seite 66
Pulizia • Per la pulizia, utilizzare un panno morbido. Non utilizzare solventi diversi dall'acqua. Temperatura di funzionamento raccomandata: 0˚C (32˚F) - 45˚C (115˚F) Simboli delle etichette e loro significati Marchio di conformità della Comunità europea. Autorizzazione all'affissione del Marchio CE nel 2011 Numero del modello Avvertenza Numero di serie...
Seite 67
Smaltire in conformità con le normative locali e nazionali in vigore Conservare a temperature comprese tra -20˚C (-4˚F) e +55˚C (131˚F) Tollera un range di pressione atmosferica 130 kPa compreso fra 69,6kPa e 130kPa, che equivale ad un'altitudine compresa fra 3000 m sul livello del 69.6 kPa mare e 380 m sotto il livello del mare.
Seite 68
Tipo di impianto HiRes HiRes 90K Advantage Naída CI Q90 ✓ ✓ ✓ Naída CI Q70 ✓ ✓ ✓ Naída CI Q30 ✓ ✓ ✓ Neptune ✓ ✓ ✓ Harmony ✓ ✓ ✓ ✓ Auria ✓ ✓ ✓ Processore sonoro ✓ ✓...
Seite 69
Tipo di impianto HiRes HiRes 90K Advantage SClin2000 ✓ ✓ SoundWave 1.4 ✓ ✓ (o versioni precedenti) SoundWave 2.0 ✓ ✓ ✓ SoundWave 2.1 ✓ ✓ ✓ ✓ SoundWave 2.2 ✓ ✓ ✓ ✓ SoundWave 2.3 ✓ ✓ ✓ ✓ Solo su Harmony...
Seite 70
Tipo di processore Naída Neptune Harmony Auria Antennina universale ✓ ✓ ✓ ✓ ✓ concava ✓ ✓ ✓ ✓ ✓ AquaMic ✓ ✓ Antennina Auria ✓ ✓ HR90K Antennina ✓ ✓ ✓ Platinum Richiede il contenitore AquaCase™...
Seite 71
Tipo di impianto C1 CII HiRes 90K HiRes 90K Advantage Antennina universale ✓ ✓ UHP concava ✓ ✓ ✓ ✓ AquaMic ✓ ✓ ✓ Antennina ✓ ✓ Auria HR90K Antennina ✓ ✓ ✓ ✓ Platinum Naída CI Q90, Naída CI Q30 e AquaCase sono disponibili soltanto nei mercati in cui è...
