To protect the environment, please try to recycle the packing material as much as possible. Check the contents: Check that the carton contains the following items: User manual PPA-101 IR remote 1 Wireless hand mic 1 Wireless beltpack with headset mic.
In the event of serious operating problems, stop using the appliance and contact your dealer immediately. Please use the original packing when the device is to be transported. Due to safety reasons it is prohibited to make unauthorized modifications to the unit. JB SYSTEMS ® 2/39 PPA-101...
Seite 5
[REPEAT ONE]: repeat the current track. [REPEAT FOLDER]: repeat current folder. [REPEAT ALL]: repeat all tracks on the USB-memory. This is the “standard” playback mode. [REPEAT RANDOM]: play all tracks in random order. JB SYSTEMS ® 3/39 PPA-101...
Seite 6
11. ANTENNA FM-RADIO: connect the FM-antenna here for good radio reception. Not needed when the radio is not used. 12. ANTENNAS WIRELESS MICS: The PPA-101 has 2 wireless microphones, each with their own receiver antenna. Both antennas should be stored in the compartment on the back of the unit during transport.
Seite 7
!!! NEVER STORE THE UNIT WITH EMPTY BATTERIES: FIRST CHARGE THE BATTERY !!! 27. 12V CAR BATTERY INPUT: you can also connect the PPA-101 to the 12Vdc output of your car. Use the supplied 12V cable to connect the unit to the cigarette lighter connection of your car.
Put the battery switch (23) in the ON-position Connect the PPA-101 to the mains to charge the battery: the [CHARGE]-indicator (24) is lit. When the [FULL]-indicator (25) is lit, the battery is full and ready to be used.
115Vac ~ 230Vac 50/60Hz Dimensions HxWxD 550 x 325 x 280 mm Weight 15,5 kg Every information is subject to change without prior notice You can download the latest version of this user manual on our website: www.jb-systems.eu JB SYSTEMS ® 7/39 PPA-101...
Pour protéger l’environnement, essayez de recycler autant que possible les matériaux d’emballage. Vérifiez le contenu : Vérifiez que le carton contient les éléments suivants : Guide d’utilisation PPA-101 Télécommande infrarouge 1 microphone à main sans fil 1 émetteur-ceinture sans fil avec microphone de casque.
Cet appareil doit être mis à la terre pour être conforme à la réglementation en matière de sécurité. Pour éviter un choc électrique, n’ouvrez pas l’appareil. L’appareil ne contient aucun composant réparable par l’utilisateur. JB SYSTEMS ® 9/39 PPA-101...
Seite 12
Mode Bluetooth : démarrer/mettre en pause la piste audio actuelle. Mode radio : Le syntoniseur recherche la bande FM et permet de programmer automatiquement des stations FM préréglées. Appuyez de nouveau sur cette toucher pour arrêter la recherche. JB SYSTEMS ® 10/39 PPA-101...
Seite 13
11. ANTENNE RADIO FM : connectez ici l’antenne FM pour obtenir une bonne réception radio. Si la radio n’est pas utilisée, elle n’est pas nécessaire. 12. ANTENNES DES MICROPHONES SANS FIL : Le système de sonorisation PPA-101 est doté de 2 microphones sans fil, chacun avec sa propre antenne de réception. Les deux antennes doivent être rangées dans le compartiment à...
Seite 14
27. ENTRÉE DE BATTERIE DE VOITURE 12 V : il est possible de brancher le système de sonorisation PPA-101 à la sortie 12 V CC de votre voiture. Utilisez le câble 12 V fourni pour brancher l’appareil à la prise d’allume-cigare de votre voiture.
Le système de sonorisation PPA-101 se présentera avec le nom [« Bluetooth »] : Connectez-vous au système de sonorisation PPA-101 : l’écran (3) du PPA-01 affichera [« Connected ! »] Le système est prêt à l’emploi ! JB SYSTEMS ®...
Fermez le compartiment de rangement Placez le commutateur de la batterie (23) sur la position « ON » Branchez le système de sonorisation PPA-101 au secteur pour charger la batterie : l’indicateur [CHARGE] (24) s’allume. Lorsque l’indicateur [FULL] (25) s’allume, la batterie est entièrement chargée et prête à l’emploi.
Dimensions H x L x P 550 x 325 x 280 mm Poids 15,5 kg Toutes les informations peuvent être modifiées sans préavis Vous pouvez télécharger la dernière version de ce manuel sur notre site web : www.jb-systems.eu JB SYSTEMS ® 15/39 PPA-101...
Probeer ter bescherming van het milieu het verpakkingsmateriaal zoveel mogelijk te recyclen. Controleer de inhoud: Controleer of de doos de volgende artikelen bevat: Gebruiksaanwijzing PPA-101 IR-afstandsbediening 1 draadloze handmicrofoon; 1 draadloos riempack met hoofdtelefoon met microfoon;...
Dit apparaat moet worden geaard om aan de veiligheidsvoorschriften te voldoen. Open het apparaat niet, om elektrische schokken te voorkomen. Er bevinden zich geen door de gebruiker te repareren onderdelen in het apparaat. JB SYSTEMS ® 17/39 PPA-101...
Seite 20
6. [FOLDER]-toets: wordt alleen gebruikt als de audiospeler actief is. Wordt gebruikt om het scherm in de mapmodus te zetten. Gebruik de NUMMER-toetsen om door de mappen en nummers te bladeren. Gebruik de [FOLDER]-toets weer om de gewenste map of het gewenste nummer te selecteren. JB SYSTEMS ® 18/39 PPA-101...
Seite 21
11. ANTENNE FM-RADIO: sluit de FM-antenne hier aan voor goede radio-ontvangst. Niet nodig als de radio niet wordt gebruikt. 12. ANTENNES VOOR DRAADLOZE MICROFOONS: De PPA-101 is voorzien van 2 draadloze microfoons, ieder met zijn eigen ontvangstantenne. Beide antennes dienen tijdens het transport in het vak aan de achterkant van het apparaat te worden opgeborgen.
Seite 22
!!! BERG HET APPARAAT NOOIT OP MET LEGE ACCU'S: LAAD DE ACCU EERST OP!!! 27. INGANG VOOR 12 V AUTOACCU: u kunt de PPA-101 ook aansluiten op de 12 V gelijkspanning sigarettenaansteker van uw auto. Gebruik de meegeleverde 12 V kabel om het apparaat aan te sluiten op de aansluiting voor de sigarettenaansteker van uw auto.
Seite 23
Activeer de [Bluetooth]-functie op uw smartphone/tablet en zoek naar [Bluetooth]-toestellen. De PPA-101 verschijnt met de naam [“Bluetooth”]: Maak een verbinding met de PPA-101: het scherm (3) op de PPA-101 geeft [“Connected!”] aan. Gereed voor gebruik! JB SYSTEMS ®...
Seite 24
Zet de accuschakelaar (23) in de stand ON (AAN). Sluit de PPA-101 aan op het lichtnet om de accu op te laden: de [CHARGE]-indicator (24) brandt. Als de [FULL]-indicator (25) aan gaat, is de accu vol en gereed voor gebruik.
Seite 25
Afmetingen H x B x D 550 x 325 x 280 mm Gewicht 15,5 kg Alle informatie is onderhevig aan wijzigingen zonder voorafgaande kennisgeving. U kunt de nieuwste versie van deze handleiding van onze website downloaden: www.jb-systems.eu JB SYSTEMS ® 23/39 PPA-101...
Wenn sich der Netzschalter in der Stellung OFF (Aus) befindet, ist dieses Gerät nicht vollständig vom Netz getrennt! Zur Einhaltung der Sicherheitsbestimmungen muss das Gerät geerdet sein. Zur Vermeidung eines elektrischen Schlages nicht das Gehäuse öffnen. Im Geräteinneren befinden sich keine zu wartenden Teile. JB SYSTEMS ® 25/39 PPA-101...
Seite 28
4. Taste [SOURCE]: Wählen Sie mit dieser Taste den MP3-Player, Bluetooth oder UKW-Tuner (Radio) aus. 5. Taste WIEDERGABE/PAUSE: Player-Betrieb: Ein Audiotitel wird wiedergegeben oder die Wiedergabe wird vorübergehend angehalten. Bluetooth-Betrieb: Ein Audiotitel wird wiedergegeben oder die Wiedergabe wird vorübergehend angehalten. JB SYSTEMS ® 26/39 PPA-101...
Seite 29
11. ANTENNE UKW-RADIO: Hier wird für guten Radioempfang die UKW-Antenne angeschlossen. Nicht erforderlich, falls das Radio nicht benutzt wird. 12. ANTENNEN DRAHTLOSE MIKROFONE: Das PPA-101 besitzt 2 drahtlose Mikrofone, jedes mit seiner eigenen Empfangsantenne. Beide Antennen sollten während eines Transports in dem Fach auf der Rückseite des Geräts aufbewahrt werden.
Seite 30
!!! BEWAHREN SIE DAS GERÄT NIEMALS MIT LEERER BATTERIE AUF: LADEN SIE ZUERST DIE BATTERIE AUF!!! 27. 12 V AUTOBATTERIE-EINGANG: Sie können das PPA-101 auch an den 12 VDC Ausgang Ihres Autos anschließen. Schließen Sie das Gerät mit dem mitgelieferten 12 V Kabel an den Zigarettenanzünder Ihres Autos an.
Seite 31
Aktivieren Sie die [Bluetooth]-Funktion Ihres Smartphones/Tablets und suchen Sie nach [Bluetooth]- Geräten. Das PPA-101 zeigt den Namen [„Bluetooth“] an: Verbinden Sie sich mit dem PPA-101: Das Display (3) des PPA-101 zeigt [„Connected!“] an. Betriebsbereit! JB SYSTEMS ®...
Schließen Sie das Aufbewahrungsfach. Stellen Sie den Batterieschalter (23) in die Stellung ON. Schließen Sie das PPA-101 an eine Steckdose an, um die Batterie aufzuladen: Die [CHARGE]-Anzeige (24) leuchtet auf. Wenn die [FULL]-Anzeige (25) leuchtet, ist die Batterie voll und betriebsbereit.
115 VAC bis 230 VAC, 50/60 Hz Abmessungen H x B x T 550 x 325 x 280 mm Gewicht 15,5 kg Diese Angaben können sich ohne gesonderten Hinweis ändern. Sie können die neueste Version dieser Bedienungsanleitung von unserer Website www.jb-systems.eu JB SYSTEMS ® 31/39 PPA-101...
Para proteger el medio ambiente, intente reciclar el material del embalaje en la mayor medida posible. Compruebe el contenido: Verifique que la caja contenga los elementos siguientes: Manual del usuario PPA-101 Mando a distancia IR 1 micrófono inalámbrico de mano 1 micrófono diadema con petaca.
Este aparato debe tener conexión a tierra para cumplir las normativas de seguridad. Para evitar descargas eléctricas, no lo abra. Dentro no hay componentes que puedan ser reparados por el usuario. JB SYSTEMS ® 33/39 PPA-101...
Seite 36
Funcionamiento del Bluetooth: para iniciar/pausar la pista de audio actual. Modo radio: la sintonizadora de radio busca en la banda FM y programa automáticamente las emisoras FM presintonizadas. Vuélvalo a pulsar para dejar de buscar emisoras. JB SYSTEMS ® 34/39 PPA-101...
Seite 37
11. ANTENA radio FM: conecte aquí la antena FM para obtener una buena recepción de la radio. Sin función cuando no está en modo radio. 12. ANTENAS DE LOS MICRÓFONOS INALÁMBRICOS: El PPA-101 tiene dos micrófonos inalámbricos, caca unos con su propia antena de recepción. Ambas antenas se pueden guardar en el compartimiento trasero de la unidad durante el transporte.
Seite 38
BATERÍA!!! 27. ENTRADA DE LA BATERÍA DE 12V DEL AUTO: también puede conectar el PPA-101 a la salida de 12 V CC de su auto. Use el cable de 12 V suministrado para conectar la unidad a la conexión del mechero de su auto.
Seite 39
34. MINI XLR DE 3 PINES: se usa para conectar el micrófono diadema suministrado. 35. MICRÓFONO DE DIADEMA: incluido con el PPA-101. También puede usar un segundo micrófono de mano en vez de la combinación micrófono diadema/petaca. (disponible como opción) 36.
Coloque el interruptor de la batería (23) en la posición ON. Enchufe el PPA-101 a la red eléctrica para cargar la batería: el indicador [CHARGE] (24) se iluminará. Cuando el indicador [FULL] (25) se ilumine, la batería estará completamente cargada y lista para usar.
Dimensiones Al x An x P 550 x 325 x 280 mm Peso 15,5 kg Esta información está sujeta a cambios sin notificación previa Puede descargar la versión más reciente de este manual de usuario en nuestro sitio Web: www.jb-systems.eu JB SYSTEMS ® 39/39 PPA-101...
