BEDIENUNGSANLEITUNG
// INSTRUCTION MANUAL
CRIMPZANGE
080.000.062.000.000
Crimpstelle
//
Crimping point
Crimpkrafteinstellung
Setting for crimping force
HEXAGONAL-CRIMPZANGE
LEITUNGSQUERSCHNITTE 1,5–6 mm
Die Hexagonal-Crimpzange wird zum Vercrimpen von gedreh-
ten Kontakten mit einer Leitung verwendet. Die optimale Kraft-
übersetzung sorgt für komfortables Arbeiten.
Die Zange eignet sich für einen maximalen Querschnittsbe-
reich von 1,5 bis 6 mm
2
. Dieser Bereich kann je nach Produkt-
serie abweichen.
Genauere Crimpinformationen sind dem Abschnitt „Werkzeuge
und Zubehör" des jeweiligen Produktkatalogs zu entnehmen.
SICHERHEITSHINWEISE
•
Crimpwerkzeuge erzeugen eine sehr hohe Presskraft.
Bei unsachgemäßer Handhabung kann dadurch
erhebliche Quetschgefahr bestehen!
•
Arbeiten unter Spannung sind nicht zulässig!
•
Bei Fragen kontaktieren Sie bitte den Hersteller.
Mehr Informationen auf www.odu.de
Further information at www.odu-connectors.com
// CRIMPING TOOL
Crimpbacken
//
Crimping jaws
//
Öffnung für Notentriegelung
Access to the emergency release lever
2
//
HEXAGONAL CRIMPING TOOL
CABLE CROSS-SECTIONS 1.5–6 mm
The hexagonal crimping tool is used to crimp turned contacts
with a conductor. The optimum force transmission provides for
comfortable working.
The crimping tool is suitable for a maximum cross-section
range of 1.5 to 6 mm
2
. This range may differ depending on the
product series.
More detailed crimp information can be found in the chapter
"Tools and Accessories" of the respective product catalog.
SAFETY INSTRUCTIONS
•
Crimping tools generate a very high pressing force. Incorrect
handling may result in considerable risk of crushing!
•
Working under voltage is not permitted!
•
For questions, please contact the manufacturer.
2
