Hedson IRT COMBI 4-1 IR/UVA Betriebsanleitung Seite 97

Rev. Change no
1 7799
POS.
1
2
3
4
5
6
7
8
9
10
11
12
Material
Drawn date
2016-11-10
714812 rev 2
0- SERIE
1
PART.NO.
713785 HANDLE
750630 TRANSFORMER
750227 SOLID STATE RELAY (IR)
193942 SOLID STATE RELAY (UV)
195501 CAPACITOR
713823 POWER BREAKER 32A
750433 RELAY (SAFETY SWITCH FILTER GLASS)
750697 BALLAST
750366 KEYBOARD
750220 DISPLAY
713755 DISPLAY UNIT COVER
750512 PCB IR/UV
Surface finish
Approved by Drawn by
MF
Certified by
Description
SPARE PART LIST CONTROL UNIT
Change description
2
3
4
5
6
7
8
DESCRIPTION
Dimension
Designed by General Tolerance
AL
Rev. by Appr. by Appr. date
MF MF 2016-10-28
9 10 11 12
701039
Note
Scale
ISO 2768-m 1:10
E
Status
Approved
Article no
701039
Sheet
5 (5)
Rev
1
97
