Controls
S
V1
L Light Switches the lighting system on and off.
S Led Motor running led.
V1 Motor Switches the extractor motor on and off at
low speed. Used to provide a continuous
and silent air change in the presence of light
cooking vapours.
V2 Speed Medium speed, suitable for most operating
conditions given the optimum treated air
flow/noise level ratio.
V3 Speed Maximum speed, used for eliminating the
highest cooking vapour emission, including
long periods.
Lighting
1
Lamp Power (W)
4
4
L
V2
V3
2
Socket Voltage (V)
E14 220 – 240
Dimension (mm)
107 x 37 DRBB/F-4-220-240-E14-35/100
ILCOS Code
