Sterling Power USA Pro Power SBR Anleitung

Pro
Power SB (R)
Basic Installation
Fuse
_
+
Battery
DO NOT OPEN UNIT | HIGH INTERNAL VOLTAGE | PLEASE READ AND UNDERSTAND THE INSTRUCTIONS PRIOR
TO INSTALLING OR OPERATING THIS PRODUCT | SHOULD ONLY BE INSTALLED BY A QUALIFIED PERSON
Copyright © 2016
Sterling Power
V1.0 June 2016
Pure Sine Wave Inverters
Pure sine wave inverter
Pro Power SB
D
4
Sterling Power Products Ltd.
ProDigital
www.sterling-power.com
Designed and developed in England:
www.sterling-power-usa.com
Technology
Made in China
Simply connect the positive and negative terminal of the inverter to the 12V
or 24V battery terminals. Use an appropriate fuse in the positive line.
Connect the AC appliance to the AC socket (up to 3000W through the
sockets - even if you have the 4KW / 5KW unit). The Live Earth Neutral
studs under the bottom right panel can be used to fasten AC cable down for
use in a distribution panel (max 5000W through the appropriate sized
cable). Then flick the on/off switch to turn on the inverter.
www.sterling-power-usa.com
RoHS
compliant
e
8
Pure
sine wave
output
3000W - 5000W
(Part No SWR)
WARNING: Do not open
High internal voltage
please read and understand instructions
before operating or installing this unit
WARNING:
www.sterling-power.com
Warranty (2 years return to factory)
EN60950-1
EN55022: A2:2003 CLASS B
EN55024:2003
EN61000-3-2:2000
EN61000-3-3:1995/A1:2001
IEC61000-4-2:A2:2003
IEC61000-4-3:20002/A1:2002
IEC61000-4-4:2004
IEC61000-4-6:A1:2004
IEC61000-4-8:A1:2000
Part No:
SIB12(24)3000
SIB12(24)4000
SIB12(24)5000
Optional
remote control
with 10 meter
cable
Live
To AC distribution
Earth
Neutral
To AC appliances
