Exploded View Arc Midi R2
1. Front panel
2. Mounting bracket for fans including fan filter
3. 2x USB 3.0
4. Removable upper hdd cage
5. Lower hdd cage
6. Hdd mounting bracket
7. Bottom dust filter
8. Removable top panel
9. Window side panel
10. Air intake
11. Fan controller switch
