Previous Track: Press this button to go to the previous audio track from a Bluetooth, USB, or SD
card source.
22
Note: When listening to Bluetooth sources, pressing this button may go to another playlist or music
genre in some apps.
17.
Play/Pause: Press this button to play/pause an audio track from a Bluetooth, USB, or SD card
source.
1
18.
Reverb: Adjust this knob to control the amount of reverb applied to the wired and wireless mic
channels.
19.
Aux In 1 Volume: Adjust this knob to control the volume for the Aux 1 input.
20.
Aux In 2 Volume: Adjust this knob to control the volume for the Aux 2 input.
2
21.
3-Band EQ: Adjust these knobs to control the treble, mid-range, and bass frequencies for the input
signal.
22.
NFC (near-field communication): Touch and briefly hold your supported and enabled device to the
3
NFC logo to pair the device.
23.
Wireless Antennas: Adjust the antennas to get the best wireless mic reception.
Rear Panel
1
2
1.
Aux Input 1: Connect a line-level device, such as a CD player, laptop, smartphone, or media device, to
this 1/8" (3.5 mm) input.
2.
Aux Input 2: Connect a line-level device, such as a CD player, tablet, smartphone, or media device to
these coaxial inputs.
3.
USB Ports: Both USB ports are capable of 2.1A charging. The top USB port also supports USB flash
drive playback of WAV, MP3, and WMA files.
4.
SD Card Slot: Connect a SD card here to play your WAV, MP3, and WMA files.
5.
XLR+1/4": Connect dynamic microphones to these mic inputs.
6.
Mic/Line Switch: Press this switch in to have the gain set for mic level sources. Have the switch in the
outward position for line-level sources.
7.
Line Output: Connect this 1/4" TRS (6.35 mm) output to another Audio Commander.
8.
Wireless Receivers: Select the wireless mic channel using the Up/Down buttons and press the Set
button to link the channel to the wireless mic. See
details.
Power Input: Connect the included power cable here.
9.
Energy Saving Mode: Audio Commander will enter a low-power "sleep" mode after 60 minutes if no
Bluetooth music or audio input source is playing through it. To resume normal operation, press any
button.
10. Power Switch: Adjust this switch to power Audio Commander on/off.
4
7
8
5
9
6
11 12
3
4
8
15
16
10
17
13
14
1
5
6
Operation > Wireless Microphone Setup
23
18
19
20
7
10
10
9
21
for more
