Outlets on the rear panel
The following outlets are available on the back panel of the Autark
:
DS512
3 4
1
2
1.

POWERCON IN / POWERCON OUT

Connect the included power
IN
socket. To do this, insert the power
turn it clockwise until it locks into place: now, the plug is firmly at-
tached to the device and cannot be accidentally removed. In order
to unplug the plug, pull the spring-mounted catch back and turn the
plug counterclockwise.
NOTE:
power CON
incorrect connections. This makes it also impossible to acciden-
tally connect speaker plugs, which are similar in design.
You can daisy-chain the applied power supply to subsequent devices
via the POWERCON OUT
5
2. socket
DC 12V IN
You can connect an optional 12 V
IN socket. The assignment is printed below the socket and is as
PIN
follows:
Assignment
Pin 1: negative phase
Pin 2: not used
Pin 3: not used
Pin 4: positive phase, +12V
7
Nowsonic Autark DS512
User manual
power cord with the
CON
plug into the socket and
CON
sockets offer mechanical protection against
socket.
power supply via the
AC
