Seite 1
Montageanleitung und Hinweise zum Betrieb Assembly and operating instrustions Manual de montaje e instrucciones de uso Manual de montagem e instruções de uso 安装与操作说明...
Seite 2
Content Page Montageanleitung und Hinweise zum Betrieb Deutsch (DE) Assembly and operating instructions English (EN) Manual de montaje e instrucciones de uso Español (ES) Manual de montagem e instruções de uso Português (PT) 安装与操作说明 漢語 Declaration of conformity and incorporation...
Seite 3
Montageanleitung und Hinweise zum Betrieb...
Der Schmierstoffgeber darf nur den technischen Daten entsprechend eingesetzt werden. Diese Werte dürfen auf keinen Fall überschritten werden. Eigenmächtige bauliche Veränderungen an dem Schmierstoffgeber sind nicht zulässig. Für daraus entstehende Schäden an Personen und Maschinen übernimmt BEKA keinerlei Haftung.
Seite 6
Verwendung zugesichert und nur unter den folgenden Bedingungen übernommen: Der Schmierstoffgeber wird entsprechend der Montageanleitung und den Hinweisen zum Betrieb verwendet. Umbau- und Reparaturarbeiten an dem Schmierstoffgeber dürfen nur von BEKA durchgeführt werden. Die Haftung ist auf den Wert des Schmierstoffgebers beschränkt.
04 - Funktionsbeschreibung D i e B E K A O N E 1 2 0 i s t e i n e l e k t r o - mechanischer Schmierstoffgeber für die Befüllkupplungsnippel Aktivierungskappe Schmierung einzelner Schmierstellen mit Öl oder Fett.
06 - Befüllung Achten Sie beim Befüllen auf äußerste Sauberkeit. Befüllen Sie die BEKAONE120 mit der Handhebelfettpresse: Aktivierungs kappe abnehmen. 2. Befüllkupplung auf den Befüllkupplungsnippel gerade aufstecken. 3. Den Behälter langsam bis zur Markierung „max.“ befüllen. 4. Befüllkupplung entfernen und Befüllkupplungsnippel reinigen. Aktivierungskappe wieder aufsetzen.
Seite 11
06 - Befüllung Bei der Erstbefüllung kann es zu Lufteinschlüssen im Behälter kommen. Die Lufteinschlüsse beeinflussen die Entlüftungsbohrung Folgekolben Funktion der Pumpe nicht, jedoch wird diese Luft zur Schmierstelle gefördert und die Schmierung kann u. U. Lufteinschluss verzögert bzw. unterbrochen werden. im Schmierfett Richtung Entlüftung Um die Lufteinschlüsse zu entfernen, befüllen Sie die...
06 - Befüllung Auswahl der Monatseinstellungen Die geförderte Schmierstoffmenge variiert je nach der gewählten Monatseinstellung (s. Tabelle). Monatseinstellung Schmiermenge pro Schmiermenge pro Monat Woche 5 cm 1,1 cm 10 cm 2,3 cm 20 cm 4,6 cm Beispiel: gewählte Monatseinstellung 12 Monate, 40 cm 9,2 cm Schmiermenge: 10 cm im Monat/2,3 cm pro Woche...
07 - Einstellung Die Aktivierungskappe ist der Schlüssel zur Bedienung der BEKAONE120. Sie wird benötigt, um wichtige Funktionen einzustellen, wie z. B. das Ein- und Ausschalten oder das Einstellen der Laufzeit. Einschalten und Einstellen der Laufzeit < Die Aktivierungskappe Die Kappe auf den roten Punkt setzen und solange halten, bis die a b n e h m e n u n d z u m rote LED 5x aufgeleuchtet hat.
08 - Zwischenschmierung und Entlüftung Aktivieren Sie die Zwischenschmierung: Um die BEKAONE120 zu entlüften (z. B. nach Erstbefüllung oder Befüllung einer leeren BEKAONE120) Um Zwischenschmierung durchzuführen Um Restkapazität der Pumpe abzufragen (s. „Kapazitätsabfrage / LED-Meldungen“) Bei Erstbefüllung: Führen Sie die Zwischenschmierung nach der Erstbefüllung mindestens 5 Mal durch, bis der Schmierstoff nahezu luftblasenfrei austritt.
09 - Montage und Inbetriebnahme Achten Sie vor der Montage darauf, dass die BEKAONE120 richtig eingestellt und entlüftet ist. Füllen Sie vor Montage die Schmierstelle und Fettleitungen bzw. Verlängerungen mit dem entsprechenden Schmierstoff vor. Sie können dafür z. B. die Handhebelfettpresse nutzen. 1.
10 - Kapazitätsabfrage / LED-Meldungen Die Restkapazität der BEKAONE120 wird nach jeder regulären Dosierung am LED-Band angezeigt (siehe Grafik und Tabelle). Um die Restkapazität explizit abzufragen, aktivieren Sie die Zwischenschmierung. Verbleibende Mögliche Befüll- Verbleibende zyklen Behälterentleerung Schmierimpulse Fördermenge (komplette Behälter) (Zyklen) >...
Seite 17
Assembly and operating instructions -16-...
01 - Table of contents Chapter Page Table of contents General safety instructions Technical data Functional description Suitable lubricants Filling Adjustment Intermediate lubrication and ventilation Assembly and start-up Capacity check / LED messages -17-...
The lubricator may only be operated in accordance with the technical data. The respective technical values may in no case be exceeded. Unauthorized modifications of the lubricator are not permitted. BEKA assumes no liability for resulting personal injury or property damage.
Seite 20
Liability is limited to the value of the lubricator Guarantee and warranty for any damage of the lubricator caused by use of improper lubricants will expire BEKA will generally not assume any liability for incorrect operation or adjustment of the lubricator Obligations of the owner / operator Discharge leakages of hazardous substances must be drained in a way that avoids risks for persons or the environment.
03 - Technical data 120 ml Lubricant volume oil ISO VG = 32 - 680 mm /s Lubricant grease up to NLGI class 2 (also with solid lubricants*) Pump type piston pump 0,24 ml / stroke Dosage volume No. of discharges max.
04 - Functional description The BEKAONE120 is an electromechanical lubricator designed to supply single Activation cap Filling zerk lubrication points with oil or grease. The lubricator is intended for stand-alone Follow-up piston use as the energy supply is provided by a battery pack.
BEKAONE120. degradble lubricants, lubricants with In case of indirect assembly, keep the lubrication lines as short H1-license and so on), please consult as possible to avoid additional load on battery due to the BEKA. backpressure in the lines! -22-...
06 - Filling Pay attention to utmost cleanness when refilling the reservoir. Use a hand-lever grease gun to fill the BEKAONE120: 1. Remove the activation cap. 2. Put the filling coupling straight onto the filling zerk. 3. Slowly fill the reservoir up to the marking „max.“. 4.
Seite 25
06 - Filling With the initial filling, air might get entrapped in the Ventilation Follow-up reservoir. These air inclusions do not affect the function piston hole of the pump, but they are transported to the lubrication point and lubrication may possibly be Air in the delayed or interrupted.
Seite 26
06 - Filling Month-setting options The delivered amount of lubricant varies on the selected month setting (see table). Lubricant amount Lubricant amount Month setting per month per week 5 cm 1,1 cm 2,3 cm 10 cm 4,6 cm 20 cm Example: selected setting 12 months, 9,2 cm 40 cm...
07 - Adjustment The activation cap is the key component of the BEKAONE120. Use the activation cap to set important functions such as power on and off or adjusting the operation time. Switching on and adjusting the operation time < Remove the activation cap Place the cap on the red point and wait until the red LED has flashed and guide it to the red point...
08 - Intermediate lubrication and ventilation Activate the intermediate lubrication: To ventilate the BEKAONE120 (e. g., after the initial filling or if you want to fill the empty lubricator) To perform an intermediate lubrication To check the remaining capacity of the pump (see „Capacity check / LED messages“) For initial filling: Initiate an intermediate lubrication at least 5 times after initial filling until the lubricant escapes with...
09 - Assembly and start-up Please remember to adjust and ventilate the BEKAONE120 prior to assembling it. Prior to assembly, prefill the lubrication point and lubrication lines or extensions with the appropriate lubricant. You can use e.g. the hand-lever grease gun for that. 1.
10 - Capacity check / LED messages The remaining capacity of the BEKAONE120 is indicated on the LED display after each normal lubrication cycle (see graphic and table). To check the remaining capacity explicitly, activate an intermediate lubrication. Filling Remaining Remaining Possible capacity...
Seite 31
Manual de montaje e instrucciones de uso -30-...
01 - Contenido Capítulo Página Contenido Instrucciones de seguridad Datos técnicos Funcionamiento Lubricantes adecuados Llenado Ajuste Lubricación intermedia y purga Montaje y puesta en funcionamiento Consulta de capacidad / Mensajes LED -31-...
En ningún caso deben excederse estos valores límites. Las modificaciones estructurales en el lubricador no están permitidas. BEKA no asume responsabilidad alguna por los daños en la máquina o en personas ocasionados por las modificaciones.
Seite 34
El lubricador se emplea conforme indicado en el manual de montaje y en las indicaciones de servicio. Los trabajos de reconstrucción y reparación en el aparato únicamente pueden ser realizados por BEKA. La responsabilidad está limitada al valor del lubricador.
03 - Datos técnicos 120 ml Volumen de depósito aceite ISO VG = 32 - 680 mm /s Lubricante grasa hasta NLGI 2 (también con lubricantes sólidos*) Tipo de bomba bomba de pist ón Volumen de dosificado 0,24 ml/carrera Vaciados de depósitos máx.
04 - Funcionamiento BEKAONE120 es un lubricador electro- Boquilla de mecánico para lubricar con aceite o grasa acoplamiento Tapa puntos de lubricación individuales. de llenado de activación El lubricador ha sido diseñado para un Plato servicio autónomo, ya que el suministro de seguidor energía se realiza mediante un paquete de pilas.
05 - Lubricantes adecuados Lubricantes adecuados Agip GR/MU EP 2 Grasa multiusos, KP2K-30 (DIN 51825): Agip GR MU/EP2 - Montado directamente Agip GR MU/EP 2 Jabón de litio, aceite mineral Agip GR MU/EP2 - Conducto Ø8x1,30 cm V(40) = 110 mm²/s, NLGI 2 Rango de temperatura de uso del Agip GR MU/EP2 - Conducto Ø8x1,100 cm lubricante: -30 °C a +120 °C...
06 - Llenado Al llenarlo preste atención a la máxima limpieza. Llene BEKAONE120 con la prensa de grasa de palanca manual: 1. Retirar la tapa de activación. 2. Insertar recto el acoplamiento de llenado en engrasador de llenado. 3. Llenar lentamente el depósito hasta la marca “máx.”. 4.
Seite 39
06 - Llenado Durante el primer llenado pueden quedar aire en el Plato sequidor Orificio de purga depósito. Este aire no afectan al funcionamiento de la bomba, sin embargo, este aire se bombea al punto de lubricación y la lubricación puede retardarse o Bolsas de aire interrumpirse bajo determinadas circunstancias.
Seite 40
06 - Llenado Selección de los ajustes mensuales La cantidad de lubricante bombeado varía según el ajuste mensual seleccionado (ver tabla). Ajuste mensual Cantidad de Cantidad de lubri- lubricante al mes cante a la semana 1,1 cm 5 cm 2,3 cm 10 cm 4,6 cm 20 cm...
07 - Ajuste La tapa de activación es la llave para operar el BEKAONE120. Es necesaria para ajustar determinadas funciones como, por ejemplo, el prendido y apagado o el ajuste del tiempo de marcha. Prendido y ajuste del tiempo de marcha <...
08 - Lubricación intermedia y purga Active la lubricación intermedia para: Purgar el BEKAONE120 (p. ej. tras un primer llenado o un llenado de un BEKAONE120 vacío) Realizar lubricaciónes intermedias Comprobar la capacidad restante (ver „Consulta de capacidad / Mensajes LED“) El primer llenado: Realice la lubricación intermedia después del primer llenado al menos 5 veces hasta que el...
09 - Montaje y puesta en funcionamiento Antes del montaje preste atención a que el BEKAONE120 esté ajustado y purgado correctamente. Antes del montaje llene el punto de lubricación y la línea de grasa o la prolongacion con el lubricante correspondiente.
10 - Consulta de capacidad / Mensajes LED La capacidad electrica restante del BEKAONE120 se muestra después de cada dosificación regular en la cinta de LED (ver gráfico y tabla). Para consultar la capacidad restante active la lubricación intermedia. Descargas de Caudal Impulsos Ciclos...
Seite 45
Manual de montagem e instruções de uso -44-...
Seite 46
01 - Índice Capítulo Página Índice Avisos gerais de segurança Dados técnicos Descrição das funções Lubrificantes apropriados Carga e recarga Regulagem Lubrificação intermediária e liberação de ar Montagem e colocação em funcionamento Consulta de nível / Avisos LED -45-...
Estes valores não podem ser excedidos em nenhuma hipótese. Modificações não-autorizadas no lubrificador automático ficam terminantemente vedadas a qualquer pessoa. No caso de danos advindos de tais modificações a pessoas ou equipamentos, a BEKA não assumirá qualquer tipo de responsabilidade sobre o ocorrido.
Seite 48
A responsabilidade em caso de danos se limita ao valor do lubrificador em questão. No caso de danos por uso incorreto ou carga com lubrificante inadequado, extinguem-se garantia do fabricante. A BEKA não se responsabiliza no caso de danos causados por erros de operação ou regulagem/programação do lubrificador.
03 - Dados técnicos Volume de lubrificante 120 ml Lubrificante ó leo ISO VG = 32 - 680 mm /s graxa até NLGI 2 (também com lubrificantes s ó lidos*) Tipo da bomba de pistão Volume de dosagem 0,24 ml por impulso Esvaziamentos do reservatório máx.
04 - Déscrição das funções BEKAONE120 é um lubrificador automático eletromecânico, para lubrificação de Bico de recarga Capa de acionamento pontos de graxa ou óleo individuais. O lubrificador foi concebido para um Pistão-guia o p e r a ç ã o a u t o m á t i c a , j á q u e a alimentaçao se dá...
05 - Lubrificantes apropriados Agip GR/MU EP 2 Lubrificantes apropriados Agip GR MU/EP 2 - montagem direta Graxa multiuso, KP2K-30 (DIN 51825): Agip GR MU/EP 2 Sabão de lítio, óleo mineral Agip GR MU/EP 2 - tubulação ø 8x1,30 cm V(40) = 110 mm²/s, NLGI 2 Intervalo de temperatura de uso Agip GR MU/EP 2 - tubulação ø...
06 - Carga e recarga Ao carregar de lubrificante observar extrema limpeza. Carregue o BEKAONE120 com a graxeira manual: 1. Retirar a capa de acionamento ou ativação. 2. Conectar a boca do carregador perpedicular ao bico de recarga. 3. Carregar ou preencher o reservatório até que seja alcançada a marca „max.“.
Seite 53
06 - Carga e recarga Na primeira carga ou preenchimento pode ocorrer a inclusão de ar (bolhas) no reservatório. Essas Orificio de liberação Pistãõ-guia do ar bolhas nao afetam a funcionalidade da bomba, mas o ar contido será impulsionado até o ponto Ar incorporado d e g r a x a i n t e r r o m p e n d o c o m i s s o o à...
Seite 54
06 - Carga e recarga Definição das regulagens de ciclo mensal A quantidade de lubrificante impulsionada varia de acordo com a regulagem de ciclo mensal escolhida (veja figura). Regulagem ciclo Volume de graxa Volume de graxa mensal por mes por semana 5 cm 1,1 cm 10 cm...
07 - Regulagem A capa de acionamento é a chave para a operação do BEKAONE120. Ela é necessária para regular funções importantes, como por exemplo o acionamento liga/desliga ou a programação do tempo de funcionamento. Ligando e programando o tempo de funcionamento <...
08 - Lubrificação intermediária e liberação de ar Ativando a lubrificação intermediária: Para liberação do ar na BEKAONE120 (por exemplo após a primeira carga ou recarga de um reservatório vazio da BEKAONE120) Para execução da lubrificação intermediária Para verificar a capacidade restante (veja „Consulta de nível / Avisos LED“) Na primeira carga: Execute a lubrificação intermediária após a primeira carga por pelo menos 5x consecutivas,...
09 - Montagem e colocação em funcionamento Antes da montagem, certifique-se de que a BEKAONE120 está programada corretamente e purgada de ar. Ainda antes da montagem, preencha o ponto de lubrificação e a linha alimentadora de graxa e suas extensões com a graxa correspondente. Para isso pode-se usar, por exemplo, bombas manuais de graxa.
10 - Consulta de nível / Avisos LED A capacidade residual ou restante da BEKAONE120 é mostrada, após cada dosagem, na faixa de LEDs (veja gráfico e tabela). Para medir apenas a capacidade ou volume de lubrificante restante, ative a lubrificação intermediária Esvaziamentos do Ciclos de...
Seite 68
06 - 润滑品加注 时间设置选项 (单位:月) 泵送油脂数量的多少取决于不同的设置时间周期(见标签)。 以月为单位的周期设置 油品消耗数量/每周 油品消耗数量/每月 5 cm 1.1 cm 2.3 cm 10 cm 4.6 cm 20 cm 例如:设定12个月的润滑周期, 9.2 cm 40 cm 泵送油脂数量为10 cm 每个月/ 2.3 cm 每周 120 cm 27.5 cm 正确的注油 注油器能够在任何时候加注油脂。泵已设定好油脂的泵送数量,与注油次数无关。 以月为单位的周期设置 个月 个月...
