Cotech E0139ST2 Bedienungsanleitung

Wireless Indoor/Outdoor
Thermometer
Art.no 36-6720 Model E0139ST2
36-6720-1 E0139ST2
Please read the entire instruction manual before using the product and then
save it for future reference. We reserve the right for any errors in text or images
and any necessary changes made to technical data. In the event of technical
problems or other queries, please contact our Customer Services.
Safety
• The thermometer must not be dismantled or modified in any way.
• The thermometer is only intended for indoor use. Do not expose it to
moisture.
• The thermometer is not intended to be used as a reference thermometer
and Clas Ohlson will not be held liable for any damage which may result
from inaccurate readings.
• The batteries should be removed from the thermometer if it is not to be
used for an extended period, otherwise they might leak and damage
the thermometer. Never leave discharged batteries in the battery
compartment.
• The max and min readings will be deleted whenever the batteries are
removed.
• The thermometer must never be subjected to shocks or impacts.
NOTE:
Do not mix old and new batteries or batteries of different types.
Do not mix alkaline, regular or rechargeable batteries.
Buttons and functions
Thermometer
5
4
6
3
7
2
8
9
1
10
1. Max/min indoor temperature
2. Max/min outdoor temperature
3. Outdoor sensor signal strength
4. 12-hour display mode indicator
5. Time
6. Sensor low battery indicator
7. Outdoor temperature trend
8. Outdoor temperature
9. Thermometer low battery indicator
10. Indoor temperature
11. [ MAX/MIN/+ ] For selecting min/max temperature display mode
12. [ SET/ºF/ºC ] For selecting temperature unit, °C or °F
13. Hanging slot
14. Battery cover
15. Table stand
GREAT BRITAIN • CUSTOMER SERVICE tel. 020 8247 9300 e-mail customerservice@clasohlson.co.uk internet www.clasohlson.co.uk
postal 10 – 13 Market Place, Kingston Upon Thames, Surrey, KT1 1JZ
Sensor
16. LED indicator (flashes when data is
being sent to the thermometer unit)
17. Hanging slot
18. Battery cover
Installation
Thermometer
1. Remove the battery cover (14) to access the battery compartment.
2. Insert 2 × AAA/LR03 batteries (sold separately) observing the polarity
markings in the battery compartment.
3. Refit the battery cover.
4. Choose where the thermometer is to be placed:
- Standing on a flat surface using the table stand (15).
- Hanging on a wall using the hanging slot (13).
Sensor
1. Slide the battery cover (18) down to access the battery compartment.
2. Insert 2 × AAA/LR03 batteries (sold separately) observing the polarity
markings in the battery compartment.
3. Click the battery cover back into place.
4. Hang the sensor on a wall outside using the hanging slot (17).
Operating instructions
Temperature display
The thermometer should receive data from the sensor and display
the temperature within 3 minutes of the batteries having been inserted in both
devices.
Refer to the Troubleshooting section if there is a problem.
1. Press [ SET/ºF/ºC ] (12) to select ºC or ºF.
2. Press [ MAX/MIN/+ ] (11) to display the max or min temperature. The display
will return to displaying the current temperature after a few seconds.
11
3. Press and hold [ MIN/MAX/+ ] for a few seconds to reset the max/min
12
temperature readings.
13
Temperature trend
The temperature trend arrow (7) points in different directions depending
14
on whether the latest temperature reading is higher or lower than previous
readings.
15 • Arrow angled upwards = Temperature has risen.
• Horizontal arrow = No temperature change.
• Arrow angled downwards = Temperature has fallen.
Setting the time
1. Hold down [ SET/ºF/ºC ] for 2 seconds until the hours begins to flash.
2. Press [ MIN/MAX/+ ] to select a 12 hr or 24 hr display.
3. Press [ SET/ºF/ºC ] so that the hours begin flashing.
4. Press [ MIN/MAX/+ ] to select the correct hour.
5. Press [ SET/ºF/ºC ] so that the minutes begin flashing.
6. Press [ MIN/MAX/+ ] to select the correct minutes.
7. Press [ MIN/MAX/+ ] to complete setting the time.
Care and maintenance
Clean the product using a lightly moistened cloth. Use only mild cleaning
agents, never solvents or corrosive chemicals.
Troubleshooting guide
17
16
The thermometer •
doesn't display
18
anything.
Temperature from •
outdoor sensor not
displayed. •
•
•
•
•
Displayed •
temperature is
incorrect. •
Responsible disposal
This symbol indicates that this product should not be disposed
of with general household waste. This applies throughout
the entire EU. In order to prevent any harm to the environment
or health hazards caused by incorrect waste disposal,
the product must be handed in for recycling so that the material
can be disposed of in a responsible manner. When recycling
your product, take it to your local collection facility or contact
the place of purchase. They will ensure that the product is
disposed of in an environmentally sound manner.
Specifications
Thermometer
Temperature (indoor)
Temperature (outdoor)
Batteries
Size
Weight
Sensor
Batteries
Update interval
Frequency
Max range
Size
Weight
Check the batteries in the thermometer and
sensor.
Check that the distance between the thermo-
meter and sensor does not exceed 30 m.
Make sure that the devices are located at least
2 m from monitors and TV sets.
Avoid placing the devices on or close to window
frames made of metal.
Avoid using electronic devices such as
loudspeakers which operate at the same
frequency (433 MHz), close to the devices.
Check the batteries in the thermometer and any
connected sensors.
Remove the batteries, wait awhile and then
reinsert them.
Remove the batteries, wait awhile and then
reinsert them.
Make sure that the devices are not affected by
heat sources or air-conditioning units and such.
0 to 50 ºC (32 to 122 ºF)
−30 to 60 ºC (−22 to 140 ºF)
2 × AAA/LR03 (sold separately)
76 × 107 × 21 mm
83 g
2 × AAA/LR03 (sold separately)
60 seconds
433 MHz
30 m
38 × 100 × 18 mm
30 g
