Marantz professional Turret Benutzerhandbuch Seite 39

Headphone
Power Output
Frequency Response
THD
Audio Out
USB
USB 1/2
To PC
USB Audio In
General
Dimensions
Weight
Power
Specifications are subject to change without notice.
Trademarks & Licenses
Marantz is a trademark of D&M Holdings Inc., registered in the U.S. and other countries. Marantz Professional
products are produced by inMusic Brands, Inc., Cumberland, RI 02864, USA.
All other product names, company names, trademarks, or trade names are those of their respective owners.
130 mW max (Variable Volume Control 0-Max output)
20 Hz – 20 kHz
0.009%
1/4" (3.5 mm), 2-Channel Stereo Output with variable mix (Mic and USB
Inputs)
2 x Type A USB 3.0, 0.75 A total available current between 2 ports for
powering devices.
1 x USB-C connector / USB 3.0 connection
Class 2 compliant speaker device for audio to be monitored on
headphone output, set by user in the computer.
With Arm fully in: 16.7" (424 mm) Width including base (max)
With Arm fully out: 33.9" (860 mm) Width including base (max)
Base Dimension: 6.85" (174 mm) Width x 8.04" Length (204.1 mm)
Height with Extension: 19.6" (498.3 mm)
Height without Extension: 17.7" (448.9 mm)
7.7 lbs
3.5 kg
AC-DC Power Supply 100 ~ 240 VAC compatible
(12 VDC @ 1 Amp output)
39
