4. Operate the device

4.1 Overview about the parts

Illustrations may differ.
3
4
5
7
1 Reflector
2 Unlocking Lever
3 Photo Cell (hidden)*
4 Handle
5 Ventilation Slots
6 Umbrella Holder
7 Tripod shot
* The Photo Cell is below the red,
transparent cover on the top side
of the device
30
1
2
6

4.2 Quick start guide

NOTE
The detailed instruction for the following
operations can be found in the respective
chapters in this instruction manual.
Keep the sequences of the following opera-
tion steps when using the device for the
first time to avoid damages on the device.
WARNING
Please note the safety notes in the
respective chapters throughout
operation.
1. Demount protection cap
2. Mount reflector
3. Insert modeling lamp
4. Mount reflex umbrella (optional)
5. Connect to power supply
6. Switch on device
7. Adjust modeling lamp
8. Adjust flash output
9. Adjust audio button
10. Prepare flash trigger
11. Mount on tripod (optional)
12. Radio remote triggering
