Basisstation2
Bedienungsanleitung
Operating instructions
Istruzioni per l`uso
Instrucciónes de uso
Mode d`emploi
Orderman GmbH, Bachstraße 59,
5023 Salzburg – Österreich
www.orderman.com
Errors and misprints excepted.
Copyright, all rights reserved.
Duplication, reproduction or distribution,
even in part, is prohibited without the written consent
of Orderman Gmbh.
P3.56-247 V4.1
Orderman übernimmt keine Verantwortung für Schäden oder Verluste, die durch Anwendung dieser Anleitung
entstehen.
Orderman übernimmt keine Verantwortung für Verluste oder Ansprüche von dritten Personen, die durch die
Benützung der Basisstaion2 entstehen.
Änderungen des Inhalts dieser Anleitung sind vorbehalten, und können ohne Vorankündigung durchgeführt
werden.
Diese Bedienungsanleitung kann nicht Bestandteil eines Vertrages sein.
Orderman assumes no responsibility for injuries or losses resulting from the utilization of these instructions.
Orderman assumes no responsibility for losses or claims by third parties resulting from the use of the bas e sta-
tion 2.
The contents of these instructions are subject to changes, which can be carried out without prior notice.
These operating instructions do not constitute part of a contract.
Orderman non si assume alcuna responsabilità per danni o perdite eventualmente causati dalle presenti istru-
zioni per l'uso.
Orderman non s i assume alcuna responsabilità per danni o d iritti di terzi riconducibili all'uso della stazione ba-
se2.
Ci riserviamo di apportare alle presenti istruzioni per l'uso, senza preavviso, qualsiasi modifica al contenuto ri-
tenuta necessaria.
Le presenti istruzioni per l'uso non possono essere usate come parte integrante di un contratto.
Orderman no se responsabiliza de los daños o pérdidas que puedan ocurrir por el uso de estas instrucciones
de uso.
Orderman no s e responsabiliza de l as pér didas o exigencias por par te de ter ceros que puedan oc urrir por el
uso de la antena RF2.
Reservado el derecho de modificaciones del contenido de estas instrucciones. Dichas modificaciones pueden
ocurrir sin previo aviso.
Estas instrucciones de uso no pueden ser parte de un contrato.
Orderman décline toute responsabilité pour les dommages ou pertes causés par l'utilisation du présent mode
d'emploi.
Orderman décline toute responsabilité pour les pertes ou les revendications de tiers entraînées par l'utilisation
de la station de base2.
Sous réserves de modifications du contenu du présent mode d'emploi. Les modifications peuvent être effec-
tuées sans avis préalable.
Le présent mode d'emploi ne peut pas constituer de partie intégrante à un contrat.
© 2009 by

Werbung

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für Orderman Basisstation2

  • Seite 1 Orderman no se responsabiliza de los daños o pérdidas que puedan ocurrir por el uso de estas instrucciones de uso. • Orderman no s e responsabiliza de l as pér didas o exigencias por par te de ter ceros que puedan oc urrir por el Bedienungsanleitung uso de la antena RF2.
  • Seite 2 Schnittstellen RS 485 Interfacce Interfase RS485 (Re- RS485 Interface RS485 (rete RS485 (Red seau order- (OM Netzwerk) (OM Network) Orderman) man) Interfaccia Interfase serie Interface Schnittstelle RS 232 seriale RS232 RS232 RS232 (PC- RS232 (PC- Interface (PC – (PC-stazione...
  • Seite 3: Inhaltsverzeichnis

    Inhaltsverzeichnis / Table of Contents / Indice Tabla de materias / Sommaire Lieferumfang, Garantie Allgemeines – .............. 2 Sicherheitshinweise, Pflege Der richtige Umgang – .......... 2 Inbetriebnahme.................... 3 Technische Daten ..................4 Included, Warranty Introduction - ..............5 Safety notes, Routine care Proper use - ............
  • Seite 4: Allgemeines

    Bedienungsanleitung Basisstation2 Allgemeines Willkommen in der Welt der Basisstation2: Diese Anleitung beschreibt die Funktionen der Basisstation2. Diese ist das Bindeglied zwischen den Orderman-Funkhandterminals und der Kassa oder dem Computer und dient zur Funkübertragung. Lieferumfang zur Basisstation2: Zusätzlich zu Ihrer Basisstation2 erhalten Sie eine aufschraubbare Anten- ne, ei n O rderman-Steckernetzgerät 15V , ei n RS -232 K abel ( 1 M eter), ei -...
  • Seite 5: Inbetriebnahme

    Basisstation2 B edienungsanleitung Pflege: Vor Rei nigung des G erätes i st IMMER di e V erbindung z um S te- ckernetzgerät bzw. zum Stromnetz zu trennen! Vorsicht Pflegehinweise: Hinweis Um die A ußenseite des G erätes z u r einigen, verwenden S ie ei n weiches Tuch, das i n ei ner schwachen Lö...
  • Seite 6: Technische Daten

    Bedienungsanleitung Basisstation2 Technische Daten Betriebsfrequenzbereich: 433,150 MHz – 434,650 MHz Funkleistung: k leiner 10mW Option USA, Canada: Frequenzbereich: 902.100 MHz – 905.300 MHz Funkleistung: kleiner als 1mW Übertragungsgeschwindigkeit: Funk: 9600 baud RS232: 9600 baud – 115200 baud Datenübertragung: bidirektional, kostenfrei im 433 MHz-Band...
  • Seite 7: Introduction

    Safety notes: Caution • Base Station2 must be oper ated with the Orderman Plug i n power supply 15V which has been provided only. • Base S tation2 s hould ne ver be e xposed t o ex treme weather c onditions such as rain, hail, strong sunlight or snowfall.
  • Seite 8: Initial Operation

    The base pl ate has two hol es f or wall-mounting. Installation of the expan- sion module is described in its operating instructions manual. Additional i nformation on i nitial oper ation c an be f ound i n t he i nstallation instructions for the Orderman system.
  • Seite 9: Technical Data

    300m outdoors indoor coverage: up to 7800m². Note: the specific building construction and the presence of metallic objects can influence range Orderman Plug in power supply 15V: Input voltage: 100V – 240V Base Station2: Input voltage: 7.5V – 15V Max.
  • Seite 10: Generalità

    Norme di sicurezza: Attenzione • Usate la stazione base 2 solo con l’alimentatore Orderman 15V in dotazio- • Non esponete mai l’apparecchio a c ondizioni meteorologiche estreme, ad esempio: p ioggia, gr andine, forte irradiazione s olare o ne ve. I n c aso di danni, fate esaminare l’apparecchio dal servizio assistenza clienti.
  • Seite 11: Funzionamento

    (LED di funzionamento) compreso. Il montaggio a parete va eseguito tramite i due f ori di montaggio previsti sul fondo piastra. L’installazione del modulo di espansione è descritta nelle apposite istruzioni per l’uso. Per avere maggiori informazioni consultate le istruzioni di installazione del sistema Orderman.
  • Seite 12: Caratteristiche Tecniche

    300 metri Copertura superficiale in edifici: fino a 7.800 m². Nota: eventuali peculiarità dell’edificio o parti metalliche possono influenzare il rag- gio di azione. Alimentatore Orderman 15V: Tensione d’ingresso: 100V – 240V Stazione base 2: Tensione d’ingresso: 7,5V – 15V Max.
  • Seite 13: Generalidades

    Bienvenido al mundo de la antena RF2: Este m anual describe las funciones de l a ant ena RF 2. E sta ant ena es el nexo de unión entre el terminal portátil inalámbrico Orderman y la caja o el ordenador y realiza la radiotransmisión.
  • Seite 14: Puesta En Servicio

    La i nstalación del módulo de expansión se describe en el manual de instrucciones respectivo. En el m anual de i nstalación del s istema Orderman enc ontrará m ás información sobre la puesta en servicio.
  • Seite 15: Datos Técnicos

    300m Cobertura en edificios: hasta 7800m² Nota: Las construciones de los edificios y los objetos de metal pueden influir sobre el alcance del aparato. Cargador Orderman de 15 V Tensión de entrada: 100V -240V. Antena RF2 Tensión de entrada: 7,5V -15V Consumo máximo de potencia: 1W...
  • Seite 16: Généralités

    Contenu de la livraison de la station de base 2 : Outre votre station de base 2, vous recevez une antenne à v isser, un bloc d’alimentation 15 V Orderman, un c âble RS-232 (1 mètre), un adapt ateur DSUB9/Modular6 ainsi que cette notice d’emploi.
  • Seite 17: Mise En Marche

    L’installation du module d´ extension es t déc rite dans l a not ice d’e mploi prévue à cet effet. Vous t rouverez des i nformations c omplémentaires c oncernant l a m ise en marche dans la notice d’installation du système Orderman.
  • Seite 18: Spécificités Techniques

    : jusqu’à 7800m². indication : la construction des bâtiments et les pièces en métal peuvent influer sur le rayon d’action Blocs d’alimentation 15 V Orderman : Tension à l’entrée : 100V – 240V Station de base 2 : Tension à l’entrée : 7,5V –...
  • Seite 19: Eu - Declaration Of Conformity

    Radio frequency Interference requirements USA, Canada The Orderman base station2 has been tested and found to comply with the regulations of FCC Code of Federal Regulations, Part 15 Subpart C, Section §15.249 Industry Canada Radio Standards, Specification RSS-210 Issue 2, Section 6.1 (Category I Equipment).
  • Seite 20 Orderman GmbH, Bachstraße 59, 5023 Salzburg, Austria Tel +43/(0)662/650561-0; Fax +43/(0)662/650561-20 office@orderman.com www.orderman.com...
