Information about this operating manual
Please read the operating instructions and familiarise yourself with the unit prior to using it for the first time.
Adhere to the safety information for the correct and safe use of the unit.
Intended use
The UVC 8000, 12000 series, in the following termed unit, is a UVC clarifying unit for cleaning normal pond
water at a water temperature of +4 to +35 °C. The unit is exclusively intended for private use and may only be
employed for cleaning garden ponds with or without fish population.
Use other than that intended
Danger to persons can emanate from this unit if it is not used in accordance with the intended use and in the
case of misuse. If used for purposes other than that intended, our warranty and operating permit will become
null and void.
Safety information
Tetra has manufactured this unit to the current state of the art and the valid safety regulations. Despite of the
above, hazards for persons and assets can emanate from this unit if it is used in an improper manner or not in
accordance with its intended use, or if the safety instructions are ignored.
For safety reasons, children and young persons under 16 years of age as well as persons who cannot recognise
possible danger or who are not familiar with these operating instructions, are not permitted to use the unit!
Please keep these operating instructions in a safe place! Also hand over the operating instructions when
passing the unit on to a new owner. Ensure that all work with this unit is only carried out in accordance with
these instructions.
The combination of water and electricity can lead to danger to life and limb, if the unit is incorrectly connected
or misused. Do not operate the unit if persons are in the water! Always disconnect the power plugs from all
units in the water and from this unit prior to reaching into the water and starting work on the unit! Compare
the electrical values of the power supply with those on the type plate on the packaging or on the unit itself.
Only operate the unit when plugged into an earthed socket. The latter must have been installed in accordance
with the valid national regulations. Ensure that the protective earth wire is led to the unit. Only use electrical
equipment, adapters, extension or connection cables with an earthed contact which are approved for outside
use. The cross section of power connection cables must not be smaller than the rubber cables identified with
H05-RNF. Extension cables must meet DIN VDE 0620. Ensure that the unit is fused for a rated residual current of
max. 30 mA via a residual current-operating system (FI or RCD resp.). Keep the power plug and all connection
points dry! Protect the connection cable when burying to avoid damage. Electrical installations at garden ponds
must meet the international and national regulations valid for installers. Do not carry or pull the unit by the
connection cable! Never operate the unit if the cable or housing are defective! Dispose of the entire unit if the
cable is damaged, as the latter cannot be replaced individually. Never open the unit or its component parts,
unless this is explicitly mentioned in the operating instructions. Never carry out technical changes to the unit.
Only use original spare parts and accessories for the unit. For your own safety, consult a qualified electrician if
you have questions or encounter problems!
Attention! Dangerous ultra-violet radiation.
The radiation of the UVC lamp, even in small doses, is dangerous for eyes and skin! Never operate the UVC lamp
in a defective housing or outside of the housing.
Installation
Install the unit horizontally, with the feet downward (C), for safety reasons, deviating installation positions are
not permissible! Position the unit at a minimum distance of 2m from the pond edge to exclude flooding and such
that it is not exposed to direct sunlight.
Start-up
Attention! Dangerous electrical voltage.
Possible consequences: Death or severe injury.
Protective measures: Disconnect the power plug prior to reaching into the water and commencing work.
The unit is not pre-installed. When starting up the unit, fit the UVC lamp first (B) (see cleaning and changing
the UVC lamp) (B). Adhere to the safety information given above! Adapt stepped hose connectors to the water
supply and return in accordance with the hose diameter. Never operate the unit without water flowing through!
Switch on the pump andwait until the UVC filter is filled with water. Check all connections for leaks. Connect the
power supply. The blue colour of the control light indicates correct function.
6
Cleaning and changing the UVC lamp (Figures A-B)
Attention! Dangerous electrical voltage.
Possible consequences: Death or severe injury.
Protective measures: Disconnect the power plug prior to reaching into the water and commencing work.
For an optimum filter performance, we recommend to replace the UVC lamp after approx. 8,000 operating hours
(approximately 12 months) (B).
Opening the unit
Turn the unit head counter-clockwise against the stop, then carefully pull out. Note: A safety switch prevents
switching on the UVC lamp as long as the housing is removed.
Clean the quartz glass
Clean the quartz glass outer face with a moist cloth and check for damage. Take care handling the quartz glass,
as it is very delicate.
Changing the UVC lamp
Important! Only use lamps the designation and rating of which match the information on the type plate. Use a
piece of paper or a soft cloth to replace the bulb.
Undo the clamping screw by turning counter-clockwise, and remove the quartz glass including the O ring with
a slight turning movement. Remove the O ring from the quartz glass, clean and check for damage. Pull out the
UVC lamp and replace. Also thoroughly clean the inner and outer surfaces of the housing.
Reassembling the unit
Refit the O ring and insert the quartz glass in the unit head against the stop. Press the O ring into the gap
between unit head and quartz glass (B). Screw in the clamping screw clockwise and manually tighten. Check
the O ring at the unit head (A) for damage, ensure that the O ring is seated againt the recess at the unit head.
Carefully push the unit head into the housing while applying slight pressure. Ensure that the tenons at the
housing engage in the grooves of the bayonet closure. Turn the unit head clockwise against the stop while
applying slight pressure (the two arrows on the housing and the unit head meet). Start up the pump first, then
connect the power supply.
Storage/Over-wintering
Remove the unit at temperatures below zero degrees centigrade. Clean the unit thoroughly, check for damage
and store in a dry and frost-free environment.
Wear parts
The UVC lamp is a wearing part and does not fall under the warranty. We recommend replacing it every 12
months to ensure correct operation.
Disposal
Dispose of the unit in accordance with the national legal regulations. The UVC lamp needs special disposal.
Ask your specialist dealer.
Problem solving
Problem
UVC lamp does not light up
Incorrect pump flow rate
Unit incorrectly matched to pond size
The water is not clearing correctly
Pond extremely dirty
Lamp has no UVC capacity
Quartz glass dirty
Cause
Remedy
Check electrical connections
Check flow rate / turn down pump
Check pond volume & unit capacity
Remoce excess debris, change water
Replace lamp after 8,000hrs/ approx.
12months
Clean
