Software Utility
The PCI Express Fiber Gigabit Ethernet Adapter also includes an optional monitoring
and maintenance software utility. Run the "setup.exe" file located within the
"PEX1000MMSC2_SFP2_Utility" folder on the included CD to provide access to
configuration settings as well as testing and reporting statistics.

Connecting to a Network

Network Configuration

For connector type, cabling requirements, and maximum segment distance when
connecting the PCI Express Gigabit Ethernet Adapter to your network, please refer to
the following table:
Speed
1000Base-SX
1000Base-SX
1000Base-LX
1000Base-BX
Instruction Manual
Port Speed
Connector
Half/Full
SC, LC
2000 Mbps
SC, LC
2000 Mbps
SC, LC
2000 Mbps
SC, LC
2000 Mbps
Duplex
MMF (62.5μm)
MMF (50μm)
SMF(9, 10μm)
SMF(9, 10μm)
7
Cable
Max. Distance
10, 20, 50 km
20, 40 km
220 m
2 km
550 m
