Minimum Phase Slow Roll-Off
•
This is a FIR filter that exceeds the specification of the above IIR filter achieving -100db stop band. It is
not a linear phase filter because it has non-symmetric coefficients but has been designed to exhibit
virtually no pre-ringing (but it does have some) with the minimum of dispersion.
Linear Phase Apodizing
•
Perfectly symmetrical impulse response, hence linear phase and non-dispersive, this filter achieves a
high -96db rejection at fs/2 and exhibits the minimum of pre-ringing possible while achieving this
excellent rejection. This is the preferred filter of many of our beta-testers.
Linear Phase Fast Roll-Off
•
The ultimate FIR filter in the 'classic' linear phase category. This filter delivers ultra-high suppression of
-120db and extreme flatness in the band. It exceeds the performance of the Sabre DAC pre-installed
Fast Roll-off filter.
Linear Phase Slow Roll-Off
•
Designed as an enhanced version of the pre-installed Sabre DAC Slow-roll off filter, this is a linear
phase, hence non-dispersive, low group delay filter that has less ripple in band and higher rejection that
the Sabre Slow Roll-off filter .
Hinweis
i
Upsampling Filter werden nur benutzt, wenn das Eingangsmaterial 44,1 kHz oder 48 kHz
beträgt. Wenn DSD Daten abgespielt werden, findet der Filter keine Anwendung.
4.8 Firmware Upgrade
Alle Resonessence Labs Produkte kommen mit aktualisierbarer Firmware.
Resonessence Labs erweitert die Funktionen und korrigiert Probleme, sofern welche gefunden werden und stellt
diese auf
http://resonessencelabs.com/software-updates-for-invicta/
deutschsprachige Anleitung werden ebenfalls auf www.resonessencelabs.de bereitgestellt.
Für das Firmware Upgrade wird kein Computer benötigt sondern lediglich eine SD-Karte.
5 Technische Daten
Wandler: ESS Sabre ES9018 (2 x ES9018 bei Invicta Mirus)
•
Auflösung: 32-Bit
•
Eingänge: AES/EBU, 2 x BNC, TOSLINK, USB 2.0
•
Upsampling Filter: Sabre Fast Roll-Off, Sabre Slow Roll-Off, Minimum Phase IIR, Minimum Phase Slow
•
Roll-Off, Linear Phase Apodizing, Linear Phase Fast Roll-Off, Linear Phase Slow Roll-Off
Unterstützte Audioformate: 16/24-Bit PCM, DSD64, DSD128, DXD
•
Datenformate SD-Karte: DSF, DFF, FLAC, WAV, AIFF (Up to 384kS/s, 24bit)
•
Datenformate Album Art: PNG, BMP, JPG
•
unterstützte Speicherkarten: SD, SDHC, SDXC (up to 2 TB) (FAT32 formatiert)
•
Bildschirmauflösung: 720p / 60Hz
•
Maße: 50 x 220 x 282 mm (HxBxT)
•
Gewicht: 2,9 Kg
•
Eingangsspannung: 110-130V / 220-250V (schaltbar)
•
Stromverbrauch: 30 Watt
•
Betriebstemperatur: 0° C - 35° C
•
Lagertemperatur: 0° C - 50° C
•
INVICTA Benutzerhandbuch
bereit. Die Downloads sowie eine
