3. Controls

1) 8 way Decade Bank
2) Black 4mm terminals
3) Red 4mm terminals
4) Grey 4mmTerminal
1040 Technical Manual
1
Selects Output value of resistance.
Resistance output terminal.
Resistance output terminal.
A third terminal is to enable the case to
be earthed or connected to either output.
