Line
No. Option
CPU Options
480-MHz CPU with
8-MB Ecache and DC-to-DC
converter
400-MHz CPU with
4-MB Ecache and DC-to-DC
converter
Internal Storage Device Options
SunCD 32 CD-ROM
DVD ROM
18-GB hard disk drive
36-GB hard disk drive
DDS4 tape drive
Setting the Main Logic Board Jumpers
The following information supersedes the information presented in the section
"About the Clock Mode Select Jumper" in the Ultra Enterprise 450 Server Owner's
Guide. Contrary to the table in the section, the new Sun Enterprise 450 server main
logic board (501-5673) uses the clock mode select jumpers J2701 and J2702.
Set the clock mode jumper shunts at addresses J2701 and J2702 to correspond to the
speed of your UltraSPARC II CPU module. Verify that the jumper setting is correct
before starting the system.
Clock Speed
250-MHz
300-MHz
400-MHz
480-MHz
en-6 Sun Enterprise 450 Server 480-MHz CPU Module Guide • August 2000
+3.3 Total
VDC Amps @
Qty Amps 3.3 V
7.5
5.0
J2701 J2702
1 + 2 2 + 3
1 + 2 2 + 3
2 + 3 2 + 3
2 + 3 1 + 2
Total +12
+5 VDC Amps @ VDC
Amps 5 V Amps
6.7
5.6
0.55 0.61
0.42 0.51
0.8 0.5
0.8 0.5
0.9 0.5
Total
Amps @
12 V
