USER GUIDE FOR THE SHURE FP16A
GUIDE DE L'UTILSATEUR DE SHURE LA FP16A
BEDIENUNGSANLEITUNG FÜR SHURE FP16A
GENERAL DESCRIPTION
The FP16A is a 1-input, 6-output, compact,
self-contained audio distribution amplifier for routing
multiple audio signal feeds without incurring loss,
distortion, hum or noise. The intelligent design, reliable
components and meticulous construction of the FP16A
make it the optimum choice for broadcast stations—AM,
FM, or TV, studios or ENG vans—as well as recording
studios, duplicating houses, and telecommunications and
production facilities.
FEATURES
S
Wide–range audio frequency response
S
Up to 90 dB gain
S
Low noise, hum and distortion
S
Protected against damage from input overload
and shorted outputs; protected against RFI and
mechanically protected against incorrect battery
insertion
S
Transformer-coupled XLR input connector is
switchable to low-impedance microphone or line
level
S
Phantom power for condenser microphones
available at input
S
Six isolated, transformer-coupled XLR outputs
are switchable to low-impedance balanced mi-
crophone or 600-ohm balanced line level
