Orange LED indicates the status of
both RCA Transmitter and AMP Receiver
as follows:
LED indicator
Interpretation of the LED signal for RCA Transmitter:
2.5 s 2.5 s
Interpretation of the LED signal for AMP Receiver:
3 s 3 s
During normal operation both transmitter and receiver show
continuous orange light.
In case the RCA Transmitter is active but it cannot find
the AMP Receiver, RCA Transmitter's indicator blinks.
In case the AMP Receiver is active but it cannot find
the RCA Transmitter, RCA Receiver's indicator blinks once in 3 seconds.
2.5 s 2.5 s
LED indicator
ON - OFF 24V DC
3 s 3 s
No power supply connected
In active mode transmitting audio
No connection i.e. no receiver detected
Power is off or no power supply is connected
In active mode receiving audio
No connection i.e no transmitter detected
Wireless Amplifier RCA2AMP
