RICOO FS5624 Montageanleitung

EN
DISPLAY RISER
ASSEMBLY INSTRUCTIONS
For:
FS7024
FS5624
all colors
v.16.12
Component Checklist
IMPORTANT: Ensure that you have received all parts according to the component checklist prior to installation.
If any parts are missing or faulty, telephone your local distributor for a replacement.
Glass plate (1x)
A
Washer (4x) Threaded pin (4x)
C
45kg
(99lbs)
MAX
Supporting foot (4x)
B
Foot pad (4x)
D E
1
D x 4
screw in
D
2
A x 1
B x 4
C x 4
screw in
B
C
3 *Optional: stick the foot pads
E x 4
E
stick on
A
Done.
