Solar Mobile Phone Charger SL04
Item no. 20 00 59
1.
Intended use
This product is designed to temporarily supply mobile phones or multimedia devices with a charging voltage
of 5 V/DC when no charging cable or power socket is available. This product is also suitable for Micro USB
devices operated by rechargeable batteries.
Operation, independent of the mains supply, is possible due to the built-in solar panels. The integrated
rechargeable battery can also be charged via a power supply unit. The solar charger includes five charging
adaptors, for mobile phones among others. Moreover, the product features two bright, white LEDs and a UV
light.
For safety and approval purposes (CE), you must not rebuild and/or modify this product. If you use the product
for purposes other than those described above, the product may be damaged. In addition, improper use can
cause hazards such as short circuiting, fire, electric shock etc. Read the instructions carefully and keep them.
Make this product available to third parties only together with its operating instructions.
Several solar chargers can be connected, as desired, to increase the current; the voltage remains constant
(parallel circuit).
2.
Delivery content
•
Solar charger
•
5 x charging adaptor
•
Charger cable
•
Power supply unit
•
Operating instructions
3.
Safety instructions
Read the operating instructions carefully and especially observe the safety information.
If you do not follow the safety instructions and information on proper handling in this
manual, we assume no liability for any resulting personal injury or damage to property.
Such cases will invalidate the warranty/guarantee.
Persons / Product
•
The solar module's performance can vary depending on weather conditions. Keep this in mind when
operating a device with this product.
•
Avoid direct contact with the surface. The surface is sensitive and can be easily scratched or destroyed
through contamination.
•
The device is not a toy. Keep it out of the reach of children and pets.
•
Do not leave packaging material lying around carelessly. These may become dangerous playing material
for children.
•
Protect the product from extreme temperatures, strong jolts, high humidity, moisture, flammable gases,
vapours and solvents.
•
Do not place the product under any mechanical stress.
•
If it is no longer possible to operate the product safely, take it out of operation and protect it from any
accidental use. Safe operation can no longer be guaranteed if the product:
-
is visibly damaged,
-
is no longer working properly,
-
has been stored for extended periods in poor ambient conditions or
-
has been subjected to any serious transport-related stresses.
•
Please handle the product carefully. Jolts, impacts or a fall even from a low height can damage the
product.
•
Also observe the safety and operating instructions of any other devices which are connected to the
product.
Rechargeable battery
•
When charging, place the device on a surface that is not heat-sensitive. It is normal that a certain amount
of heat is generated during charging.
•
Rechargeable batteries must not be dismantled, short-circuited or thrown into fire. There is a risk of
explosion!
Miscellaneous
•
Consult an expert when in doubt about operation, safety or connection of the device.
•
Maintenance, modifications and repairs are to be performed exclusively by an expert or at a qualified
shop.
•
If you have questions which remain unanswered by these operating instructions, contact our technical
support service or other technical personnel.
4.
Operation
Prior to initial use, fully charge the product's integrated rechargeable battery using the
power supply unit.
Charging the battery (power supply unit)
1.
Connect the cable of the power supply unit to the product's "In" input socket. Insert the mains plug into the
wall socket.
2.
The right-hand side LED lights up orange indicating that the product is being charged.
3.
When the charging has been completed, the right-hand side LED lights up green.
Charging the battery (solar)
The charging time depends on the lighting conditions. With ideal conditions, it will take at least 16
hours for the internal battery to be fully charged.
1.
During operation, put the product on a flat, clean surface.
2.
Position the product in a sunny spot.
3.
The right-hand side LED lights up orange indicating that the product is being charged.
4.
When the charging is complete, the right-hand side LED lights up green.
Charging mobile phones / Micro USB devices
1.
Select the appropriate charging adaptor for the mobile phone. Use the Micro USB adaptor for Micro USB
devices. Connect the adaptor to the USB cable and then to the mobile phone or Micro USB device.
2.
Plug the USB connector to the device's "Out" output socket.
Version 11/11
3.
Charging is now commencing.
4.
The left-hand side LED flashes when the mobile phone is being charged.
5.
After use, disconnect the product from the mobile phone.
Torch / UV light
Never point the light beam directly at people or animals. This could cause damage to
eyes.
1.
Switch on the torch. For this, press and hold the "LED" button on the side of the product. Release the button
to switch the torch off.
2.
Switch on the UV light. For this, press and hold the "UVlight" button on the side of the product. Release the
button to switch the UV light off. The UV light allows the inspection of bank notes.
The switch on the reverse side of the product has no function with this model.
5.
Cleaning
Regularly clean the solar module, as its performance would otherwise decrease and the
surface could be irreversibly damaged.
•
To clean the surface, use a soft, antistatic and dry brush.
•
Under no circumstances use aggressive cleaning agents such as glass cleaners or chemical solutions to
clean the solar module, as the surface may otherwise be damaged.
6.
Disposal
Product
Electronic devices are recyclable waste and must not be disposed of in the household waste.
At the end of its service life, dispose of the product according to the relevant statutory regulations.
Rechargeable battery
You as the end user are required by law (Battery Ordinance) to return all used rechargeable batteries. Disposing
of them in the household waste is prohibited.
Contaminated rechargeable batteries are labelled with this symbol to indicate that disposal in the
domestic waste is forbidden. The designations for the heavy metals involved are: Cd = Cadmium,
Hg = Mercury, Pb = Lead (name on (echargeable batteries, e.g. below the trash icon on the left).
Used rechargeable batteries can be returned to collection points in your municipality, our stores or
wherever rechargeable batteries are sold.
You thus fulfil your statutory obligations and contribute to the protection of the environment.
7.
Technical data
Solar Mobile Phone Charger
Solar cell:
Nominal voltage:
Rated current:
Nominal power:
Rechargeable battery:
Battery capacity:
Output voltage:
Output current:
Adaptors:
Dimensions (W x H x D):
Weight:
Power supply unit
Input voltage:
Input current:
Output voltage:
Output current:
These operating instructions are published by Conrad Electronic SE,
Klaus-Conrad-Straße 1, D-92240 Hirschau/Germany.
All rights including translation reserved. Reproduction by any method, e.g.
photocopy, microfilming, or the capture in electronic data processing systems
require the prior written approval by the editor. Reprinting, also in part, is prohibited.
The operating instructions reflect the current technical specifications at time of print.
We reserve the right to change the technical or physical specifications.
© 2011 by Conrad Electronic SE.
Monocrystalline
5 V
200 mA
1 W
Lithium polymer
2200 mAh
5 V/DC
500 mA
Nokia 6106, Nokia 8210, Moto V3, Sony Ericsson K750, Micro-USB
15 x 72 x 128 mm
115 g
100 – 240 V/AC, 50/60 Hz
500 mA
5 V/DC
2000 mA
V3_1111_02-JU
