T-2011 USB Cassette/Record Player
Item no. 32 59 80
1. Intended use
This product is designed for the playback of records and audio cassettes. The tracks played back can be
transferred via USB to a computer and edited using the attached software. Moreover, the product also features
two integrated loudspeakers. The product can be connected to a mixer or amplifier using the cinch connector.
Power is supplied by a standard mains socket. The product is only to be used indoors in dry conditions.
For safety and approval purposes (CE), you must not rebuild and/or modify this product. If you use the product
for purposes other than those described above, the product may be damaged. In addition, improper use can
cause hazards such as short circuiting, fire, electric shock etc. Read the instructions carefully and keep them.
Make this product available to third parties only together with its operating instructions.
2. Delivery content
• USB cassette/record player
• USB cable
• Software CD
• Operating instructions
3. Equipment
• 3 playback speeds for records (33 1/3, 45 and 78 rpm)
• Autostop function
• Single adaptor
• Belt drive
• Ceramic pick-up with protective cap
• Dust cover
4. Safety instructions
Read the operating instructions carefully and especially observe the safety information.
If you do not follow the safety instructions and information on proper handling in this
manual, we assume no liability for any resulting personal injury or damage to property.
Such cases will invalidate the warranty/guarantee.
Persons / Product
• The device is not a toy. Keep it out of the reach of children and pets.
• Do not leave packaging material lying around carelessly. These may become dangerous playing material
for children.
• Protect the product from extreme temperatures, direct sunlight, strong jolts, high humidity, moisture,
flammable gases, vapours and solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, take it out of operation and protect it from any
accidental use. Safe operation can no longer be guaranteed if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor ambient conditions or
- has been subjected to any serious transport-related stresses.
• Please handle the product carefully. Jolts, impacts or a fall even from a low height can damage the
product.
• Do not place open sources of fire, such as burning candles, on or directly next to the device.
• Also observe the safety and operating instructions of any other devices which are connected to the
product.
Miscellaneous
• Consult an expert when in doubt about operation, safety or connection of the device.
• Maintenance, modifications and repairs are to be performed exclusively by an expert or at a qualified
shop.
• If you have questions which remain unanswered by these operating instructions, contact our technical
support service or other technical personnel.
5. Operating elements
Version 08/11
6
7
6. Setup
• Ensure proper ventilation when setting up the device.
• Never place the product on soft surfaces such as carpets, beds, etc.
• In addition, air circulation must not be obstructed by any objects such as magazines, tablecloths, curtains
etc. This prevents heat removal from the product and can lead to overheating (risk of fire).
• Make sure that the device is set up securely positioned on a steady surface.
• Persons can be injured if the device falls down.
• When setting up the device, make sure that the connection cables are not squeezed or damaged by sharp
edges.
• Always install the cables so that nobody can trip over them or become entangled in them. Risk of injury.
• When selecting a place to set up the device, avoid direct, intense sunlight, vibration, dust, heat, cold and
moisture.
• Make sure there are no devices with strong electric or magnetic fields such as transformers, motors,
cordless telephones or radio-controlled devices in the vicinity of the device, as they can cause interferences
in the record player.
• Never place the device on valuable or sensitive furniture surfaces without sufficient protection.
• When selecting the setup location, please take into consideration the room layout such as the whereabouts
of the nearest mains socket etc.
• The playing surface should be isolated from the floor surface.
9 10
1. Single adaptor 7. Volume control
2. Pick-up lift lever 8. Cassette player
3. Autostop control 9. USB connection
4. Speed regulator 10. Cinch connection
5. Pick-up arm 11. Power cord
6. Dust cover
1
2
3
4
5
8
11
