TOOLCRAFT TCBS 20-LI Solo Originalbetriebsanleitung Seite 15

Table of contents
1. Introduction ........................................................................................................................................................16
2. Explanation of symbols ......................................................................................................................................16
3. Intended use ......................................................................................................................................................17
4. Delivery contents ...............................................................................................................................................17
5. Safety instructions .............................................................................................................................................18
a) Important safety information ........................................................................................................................18
b) General safety information ..........................................................................................................................18
c) Charger/mains voltage ................................................................................................................................19
d) Battery .........................................................................................................................................................19
e) Operation of the cordless drill driver ............................................................................................................19
6. Product overview ...............................................................................................................................................21
7. Operation ...........................................................................................................................................................22
a) Removing battery from/inserting battery into the cordless drill driver ..........................................................22
b) Inserting tool into/removing tool from the keyless chuck .............................................................................22
c) Rotation direction switch (with safety catch) ................................................................................................22
d) Slide switch for two-speed gearbox .............................................................................................................23
e) On/off switch with speed control ..................................................................................................................23
f) Torque setting ring .......................................................................................................................................24
g) Belt clip ........................................................................................................................................................24
h) LED light to illuminate working area ............................................................................................................24
8. Troubleshooting .................................................................................................................................................25
9. Care and cleaning ..............................................................................................................................................26
10. Disposal .............................................................................................................................................................26
11. Declaration of conformity (DOC) ........................................................................................................................26
12. Technical data ....................................................................................................................................................27
Page
15
