Operation
1. Put in / replace batteries
Before putting in / replacing the batteries, the
luminaire must be turned off. Screw the closing cap
with the switch, which is located at the back part
of the light body, counter-clockwise to open and
take out the battery holder. Put the 3 AAA alkaline
batteries into the holder according to the indica-
ted directions. Place the holder in the luminaire
housing in the direction of the direction arrow.
Screw the luminaire again tightly. Attention, the
luminaire does not work when the batteries are
placed falsely.
2. For turning it on and off, press the on/off switch
located at the back part of the luminaire.
3. In order to change to the desired colour, turn the marker
of the colour changing wheel to the desired colour
(R = red / B = blue / G = green / W = white). The amount
of chooseable colours depends on the model.
Warranty
With regard to warranty and guarantee regulati-
ons, the terms and conditions valid at the time of
purchase apply.
Take a look at our latest sites at www.setolite.com/en
Cleaning and care
1. In order to remove dirt, dust, oil, grease, etc., use a
soft cloth that is lightly moistened with a mild soap
solution or water. Afterwards, dry it off with a soft,
dry cloth. Do not use corroding substances or sol-
vents for the cleaning.
2. Check regularly the condition of the batteries and
immediately replace them if they leak or are defor-
med or damaged and are no longer according to
the normal condition. All damages that are caused
by faulty batteries are excluded from the warranty.
Colour choosing wheel
Colour markings
Lens
Colour choosing marking
Housing body
Belt clip
Attention
1. The outer housing of the luminaire can get warm at
intensive use. That is normal.
2. Remove the batteries if the luminaire is not used for
a longer period of time.
3. Do not look directly into the light. This may lead to
short- or even long-term eye damages. The produ-
cer or the retailers cannot be made responsible for
these injuries.
4. Keep the luminaire away from children.
Technical data
Type CONDUCTOR LIGHT
4CLED / 3CLED / 2CLED
Illuminant 3 W 4 colour LED Chip (RBGW)
The amount of chooseable colours depends on
the model
Light colour approx. 6000 °K
(white)
Life time approx. 100.000 hours
illuminant
Batteries 3 x AAA Alkaline
Lighting approx. 2,5 hours
duration
Switch mode –
4CLED
Red: 85 lm
luminous flux
Blue: 30 lm
Green: 110 lm
White: 145 lm
IP code IP64
Weight approx. 117 g (without batteries)
Dimensions Ø 35 mm x 126 mm
Scope of delivery 3 x AAA batteries, belt holster, clip
wrist strap, operation instructions
Item no.
4CLED 78__008500
3CLED 78__008503
2CLED 78__008502
Closing cap
Battery holder
3 x AAA Alkaline
3CLED 2CLED
Red: 85 lm Red: 85 lm
--- ---
Green: 110 lm ---
White: 145 lm White: 145 lm
Open
On / Off
Closed
