Aufnehmen mit "DMS-Splitter" / Recording with "DMS-Splitter"
Matrizierung während der Aufnahme mit
zwei Matrizen
(direkte Aufnahme der Surround-Kanäle)
Statt mit zwei Matrizen kann
die Matrizierung auch mit
einem PC vorgenommen wer-
den.
Unter ww.schoeps.de/
dmsplugin.html haben Sie die
Möglichkeit sich zu registrie-
ren, um ein PlugIn zu erhal -
ten, mit dessen Hilfe Sie die
drei Kapselsignale einfach und
intuitiv dekodieren können.
* nur bei 5-Kanal-Recorder
* only with 5-channel recorder
4
SCHOEPS GmbH · Spitalstr. 20 · D-76227 Karlsruhe (Durlach) · Tel: +49 721 943 20-0 · Fax: +49 721 943 2050
FRONT
M front
S
M rear
outputs:
DMS-Splitter
M
= center
front
(passive)
S
= S
front
rear
M
rear
S
rear
center
front
M
matrix I
(VMS 5 U)
front
left
right
Dematrixing on location with two matrices
(Recording the surround channels directly)
XLR-7
KDMS 5 U
extension cable,
5 m long
XLR-7
5× XLR-3
rear
S
M
S
matrix II
(VMS 5 U)
rear
left
right
recorder
www.schoeps.de · mailbox@schoeps.de
Instead of two matrices
also a PC can be used
for dematrixing.
A "Double M/S" VST
plug-in for Windows
can be obtained by fill-
ing in a registration
form at
www.schoeps.de/
dmsplugin.html. This
plug-in supports sim-
ple, intuitive decoding
of the three micro-
phone signals.
For further information
see page 13ff.
