Safety advices:
 Installation and repairs to the equipment may only be carried out by
technicians observing the current VDE guidelines. No liability will be
assumed in the case of faulty installation and commissioning.
 Before opening the equipment pull out the power plug or remove the
power supply, otherwise there is danger of electrocution. This is also
valid for cleaning the equipment or working on the connections.
 Only use the mains cable connected to the device. Never replace any
parts or make any modifications on the mains cable. Otherwise there is a
risk of mortal injury for which we cannot be held liable.
 Providing that a serviceable fuse exists, the power cord must be pulled
out before changing the fuse. Defective fuses may only be replaced with
standard compliant fuses that have the same nominal value.
 The equipment may only be operated in dry rooms. In humid rooms or
outdoors there is danger of short-circuit (caution: risk of fire) or electro-
cution.
 Choose the location of installation or mounting so that the power plug
can be reached and pulled out of the socket easily in case of danger.
Choose the location of installation or mounting such that children may
not play unsupervised near the equipment and its connections. The
location of installation or mounting must allow a safe installation of all
cables connected. Power feeding cables as well as feeder lines may not
be damaged or clamped by objects of any kind. To prevent damage to
your equipment and to avoid possible peripheral damages, the devices
foreseen for wall mounting may only be installed on a flat surface.
 Choose the location of installation or mounting so that under no circum-
stances liquids or objects can get into the equipment (e.g. condensation,
water coming from leaking roofs or flowing water, etc.).
 Avoid exposure of the equipment to direct sunlight and to other heat
sources (e. g. radiators. other electrical devices, chimney, etc.). Devices
that are equipped with heat sinks or ventilation slots must under no
circum-stances be covered or blocked. Also ensure for a generous air
circulation around the equipment. In this way you avoid possible damage
to the equipment as well as a risk of fire caused by overheating. Abso-
lutely avoid that cables come near any source of heat (e.g. radioators,
other electrical devices, chimney, etc.).
State of the art 2018-04-05
Technical improvements, changes in design, printing- and other errors expected.
Technical data:
Frequency range (TERR | SAT) ................................ 47...862 | 950...2200 MHz
Gain (TERR | SAT) .............................................................. 18...21 | 20...25 dB
Attenuator adjustment range ............................................................. 0...20 dB
Noise figure ................................................................................................8 dB
Max. output level
3rd order max. .................................................................................. 99 dBµV
1
3rd order SAT max. 2 .......................................................................... 110 dBµV
RF connectors ..................................................................................................F
DC power pass ..............................................................................................yes
Built-in power supply ................................................................. 230 V~ / 50 Hz
Power consumption .....................................................................................3 W
Power indicator ............................................................................................LED
Equipotential bonding connection ......................................................... 4 mm²
Dimensions (W × H × D) appr. ...........................................160 × 100 × 45 mm
Protection class ..........................................................................................IP 20
1 EN50083-3 60dB KMA
2 EN50083-3 35dB KMA
Herewith AXING AG declares that the marked products comply with the valid
guidelines. You can call up the complete EU declaration of conformity for
download by entering the article in the search field at www.axing.com.
WEEE Nr. DE26869279 | Electrical and electronic components must not be
disposed of as residual waste, it must be disposed of separately.
Manufacturer EEA contact address
AXING AG Bechler GmbH
Gewerbehaus Moskau Am Rebberg 44
8262 Ramsen 78239 Rielasingen
SVS 1-00
basic-line
SAT wideband amplifier
Operation instructions
