Software Upgrade
Download through RS-232 port
OTA Download
RF Modulator [optional]
TV standard
Frequency range
Multi-media card reader [optional]
Supported cards
USB interface [optional]
Bus access cycle speed
USB host
USB device
Rear panel interface
Front-End: RF input connector
Front-End: Loop through
Output connector
RF modulator: RF input connector
RF modulator: Loop through
Output connector
TV SCART connector
VCR SCART connector
Digital Audio SPDIF
CINCH (RCA)
SVHS
Digital Audio SPDIF
Serial port
Front Panel
11 Keypads
10-digit VFD display
1 LED indicator
1 IR Sensor
2 CI slots [optional]
USB: host + device sockets [optional]
Multi-media card reader [optional]
Power requirements
Mains input voltage
Mains input frequency
Power consumption
PAL (G/I//K), SECAM-K
47 ~ 862 MHz
CompactFlash, IBM Microdrive, SmartMedia, MultiMediaCards,
SD Cards and Memory Stick
Up to 22MB/s
1 port, USB-A type
1 port, USB-B type
2 X IEC169-2, Socket
2 X IEC169-2, Plug
1 X IEC169-2, Socket
1 X IEC169-2, Plug
CVBS(output), RGB (output), L&R Audio (output), SVHS (output)
CVBS (input & output), RGB (input), L&R Audio (input & output),
SVHS (output)
1 X Coaxial, 1 X Optical
Audio – L & R, Video - CVBS
Mini-DIN (Female)
Coaxial / Optical
RS-232C (Female, DB-9)
90-260 VAC~
50 / 60 Hz
Normal operation: TBD
Standby mode: TBD
Max. : 60W
