Haemmer CLASSICA Bedienungsanleitung Seite 3

DISPLAYS AND BUTTONS
BUTTON B
NORMAL-POSITION
CROWN
2st CLICK POS.
1st CLICK POS.
BUTTON A
USING THE CHRONOGRAPH
This chronograph is able to measure and display time in 1/20 second
united up to maximum of 59 min 59 sec.
The chronograph 1/20 second hand keeps continuously for 30 seconds
after starting, and then stops at Zero position.
Measuring time with the stopwatch
1. Press button „A" to start the chronograph.
2. The chronograph can be started and stopped each time button „A"
is pressed.
3. Press button „B" to reset the chronograph and chronograph minute
and second hands return to their Zero positions.
„A" Time measurement
CLASSICA
TIME SECOND HAND
CHRONO MINUTE HAND
CHRONO 1/20 SEC. HAND
DATE
CHRONO SECOND HAND
„A" Stop „B" RESET
SETTING THE TIME
1. Pull the crown counter-clockwise out to the 2nd Click Position.
2. Turn the crown clockwise to set hour and minute hands.
3. After the time has been set, push the crown back to the Normal position.
SETTING THE DATE
1. Pull the crown counter-clockwise out to the 1nd Click Position.
2. Turn the crown clockwise to set the date.
* If the date is set between the hours of around 9:00 PM and
1:00 AM, the date may not change on the following day.
3. After the date has been set, push the crown back to the Normal position.
CHRONOGRAPH RESET (INCL. AFTER REPLACING BATTERY)
This procedure shoud be performed when the chronograph second hand
does not return to the Zero position.
1. Pull the crown counter-clockwise out to the 2nd Click Position.
2. Press the button „A" once to set the chronograph second hand to the
Zero position.
3. Press the button „B" once to set the chronograph 1/20 second hand to
the Zero position.
* The chronograph hands can be advanced rapidly by continuously
pressing button „A" or „B".
4. Once the hands are set at Zero position, reset the time and return the
crown to its normal position.
