SPARE PARTS LIST

Part
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
Description
Right housing
Tapping screw ST3.9x39
Tapping screw ST3.9x19
Foot plate
Quick release wrench
Fixing plate
Pin
Eccentric wheel
Roller support
Torsion spring
Blade
Quick plunger assembly
Saw arm holder
Roller
Big gear
Fixing ring
Washer
Needle roller bearing
Balance block
Pendulum bar
Bearing holder
Bearing 629
Brush holder
Brush holder support
Carbon brush
Rotor
Part
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
57
Spare parts
Description
Bearing
Stator
Cable sleeve
Cable
Left housing
Connecting plate
Nut
Fixing ring
Washer
Finger guard
Saw arm holder
Spring
Laser holder
Cover
Screw M3x5
Tapping screw ST2.9x16
Laser head
LED
PCB for laser
Laser head button
Pendulum switch knob
Metal ball
Spring
PCB
Switch
Terminal block
