Beginning of Operation
1. Slide the range switch to select suitable multiplier for application (if unknown, start
at "x100" and adjust to lower range as needed). Manually rotate measuring shaft to engage
the gear for selected range. Slide contact adapter (cone tip or surface speed wheel) over
measuring shaft.
2. To measure, press and hold the red pointer button
button
is released, pointer will remain in last position. To reset pointer, press and
release red button.
RPM
m/min, ft/min
Lieferumfang / Scope of delivery
Tachometer / Tachometer
Messrad / Wheel 6 inch
Messrad / Wheel 0,1 m
Messspitze / Measuring tip
Hohlspitze / Measuring funnel
Verlängerungswelle / Extension shaft
Bedienanleitung / Manual
● = im Lieferumfang enthalten / included in scope of delivery
○ = Sonderzubehör / Special Equipment
HTM-100M
●
1
○
2
●
3
●
4
●
5
●
●
to activate pointer. When red pointer
HTM-500M
HTM-100F HTM-500F
●
●
○
●
●
○
●
●
●
●
●
●
●
●
EN
●
●
○
●
●
●
●
