Icy Box IB-PCI212 Handbuch Seite 6

M.2 SATA SSD
M.2 PCI-E SSD
The above graphic shows
where to install the M.2 SSDs.
dasdgsdfgsdfbsdgvfdfcvsvbfgsrgett-
Remove the plastic layers on
nzrgeffdbgnhtrgdfbgntgfdefcvbgff
the thermal pad and stick it
on the card.
When using the M.2 SATA SSD slot a SATA
cable is needed in order to connect the
card to your pc.
Manual IB-PCI212
Remove the screws on the
top side.
Install the M.2 SSDs and
fasten the screws.
Remove and reinstall the
screw nuts on the bottom side
fitting the needed M.2 length.
If needed use the low profile
bracket .
Power
M.2 PCI-E SSD
The LED indicators work as illustrated.
M.2 SATA SSD
