Technische Daten; Abmessungen; Messdaten - Nova Nm-R Digital Bedienungsanleitung

8. TECHNISCHE DATEN

SYSTEM
Design
Principle
Frequency Response
Impedance
Rated Power
Program Power
Sensitivity @ 1W/1m
SPL max. @ 1m
Dispersion HxV
Loudspeaker High
Loudspeaker Low
Connectors
Wiring
Dimension WxHxD
Cabinet Angles
Weight
Material
Finish
Grill
Handles
Rigging
Accessories

9. ABMESSUNGEN

600

10. MESSDATEN

Frequenzganz NM-R DIGITAL
Seite 9
NM-R
multifunctional cabinet design
2 way Fullrange
45 Hz - 40 KHz
8 Ohms
400 W
600 W
97 dB
124 dB
60° x 30°
NRD 240 neodym ribbon driver
12" neodym (18 Sound)
speakon NL 4
in 1+/1- and 2+/2- loop thru
400 x 600 x 310
50° / 27°
approx. 17 kg passive / 20 kg active
15mm birch plywood
black polyurea
perforated steel
one
tripod base
2 x M 10
U - bracket
MODULE
Output Power / W @ 8 Ohms
Output Power / W @ 4 Ohms
Output Impedance / Ohms
Slew Rate V / µs
Damping Factor @ 8 ohms
Input Impedance
Gain Controls
Input Sensitivity
EQ Indicators
LED Indicators
Soft Start
Mode Switch
Tone Balance
Input Connectors
Output Connectors
Operation Voltage
300
Impedanzganz NM-R DIGITAL
NM-R
NM-R
DIGIT AL
DAM 400
230 W
440 W
Mix out flat 600 ohms
10V/µS Measured after Output Filter
>400
MIC:1.2K ohms, AUX:22K ohms,
LINE:33K ohms
MIC Level, AUX Level,
Master Volume
MIC:60 dBV, AUX:12 dBV,
LINE:0 dBV
Voice EQ, Low Cut, EQ
Power, Protect, Limit Amp, Signal
Overload, Output Pre EQ
Yes
Voice EQ (only MIC), Low Cut, EQ
Voice EQ Level, High EQ, Low EQ
MIC - XLR/Jack, AUX - Cinch,
LINE - XLR
LINE Loop Thru - Jack, MIX Out
Flat - XLR, ext. Speaker -
SPEAKON
90 V - 265 V
