Faytech TOUCHSCREEN-PC series Bedienungsanleitung Seite 6

Technische Daten Touch PC
Spezifikation
PC-Part
CPU
Front Side Bus
Chipset (North/South Bridge)
Arbeitsspeicher
BIOS
Watchdog Timer (1~255 steps by software program) ●
Wake On LAN/PCE
Festplatte
Grafik
Audio
5.1 Channel High Definition Audio Codec
Netzwerk
externe Anschlüsse
Interne I/O Anschlüsse
Erweiterungssteckplätze
COM1 schaltbar zwischen RS232/RS485; 5V/12V
via BIOS-Einstellung
Treiber
Eingangsspannung
Betriebstemperatur
Site
Intel® Atom™ processor N2600 (optional N2800)
800/1066MHz
Intel® NM10
1x2GByte DDRIII SODimm
64Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 2.0, Wfm 2.0, SM BIOS, ACPI
● (WOL, PXE)
siehe Verkaufsbeschreibung
AMD HD7410M with 512M memory
Realtek 887 8channel high definition audio codec, Audio Amplifier EUA 2012A
●
2 x Realtek PCIe Gb LAN 8111F
1x HDMI port
1x COM port (RS232/485; 5V/12V)
2x GBit LAN (RJ45) ports
4x USB 2.0 ports
2x W-LAN-Antenna connectors
Power On/Off
1 x VGA pin header
1 x 12V DC power connector (2-pin)
2 x SATA 3Gb/s connectors
1 x 4-pin SATA power connector
1 x PS/2 keyboard/mouse connector (6-pin)
1 x USB 2.0 header supports additional 2 USB 2.0 ports, 1x used for Touch
3 x RS232 COM connectors (1x used for external)
1 x LVDS connector
1 x 5-pin LCD power connector
1 x 4-pin (2x2W) audio amplifier connector (used for loudspeaker)
1 x Line-Out / Mic-In audio pin header (AAFP)
1 x S/PDIF output pin header
1 x 8-bit Digital I/O interface (4-in /4-out)
1 x Chassis Fan connector
2 x Mini Card slots with PCIe and USB interface (1 x Full Height with SIM
card interface, 1 x Half Height (W-LAN-card integrated)
1x PCIeX1 Straddle connector
●
WinXP, Win7, Win8; Linux; 32Bit/64Bit
100~240V
0° bis +60°
CP
