KNOW YOUR SCOOTER
2
1
3
9
4
6
10
SCOOTER ASSEMBLY
(Ensure all wrapping and packing materials are taken off your scooter before you start)
Slide the Handlebars onto the for tube, ensure the fork and bares are
lined up before doing so.
Avoid twisting/turning the bars as you slide it down. Doing so may
loosen the compression.
Ensure both of the bars and the clamp are touching the top of the
headset.
1 - Bars
2 - Hand Grips
3 - Clamp
4 - Deck
5 - Wheel
6 - Fork
7 - Brake
8 - Grip Tape
9 - Headset
10 - Blunt plate
Required tools for assembly
6mm Allen Key ( included)
8
When you are satisfied that your front wheel and your handle
bars are in line. Use your 5mm allen key, to tighten the bolts from
the bottom up. Do this by turning the allen key in a clockwise
rotation.
Repeat this action until thr 2 bolts are tightened securely.
Failure to tighten or install properly may result in loss of control
and injury. If you have trouble understanding these instructions,
seek assistance of a qualified mechanic.
4
7
5
