2. Unable to connect WI-FI or there is a weak signal
● Ensure the Network is working properly.
● Ensure the username and password are correct.
● Ensure the internal antenna is not blocked.
● Ensure the tablet is within the proper distance of the Network
and there is no obstruction inbetween.
3. Fail to copy files
● Ensure the tablet is connected to the computer correctly.
● Ensure there is still disc space.
● Ensure the USB cable is functioning well.
4. No sound in the earphone
● Ensure that the volume is not set to 0.
● Check whether the headset is correctly connected and if the wire
is broken.
5. General issues with the system
● When you install some third-party applications it may lead to va-
rious issues. You can restart the tablet or uninstall the applications.
6. Unable to set up E-Mail or use registration applications.
● Ensure your Network is working properly.
● Ensure the E-Mail account is correctly set up.
● Ensure your system time is the same as the local time.
● Run the "Advanced Task Manager" to stop some other applications
running.
7. The memory capacity is different from the nominal figure
● Just like the hard disc on a computer, the capacity shown is usually
less than the nominal capacity; this is due to different unit
conversion used by computer and storage device manufacturers.
On a computer, 1 GB = 1024 MB, but storage device manufactu-
rers use 1 GB = 1000 MB as default. The actual capacity is not
lower.
● The OS of this tablet pre-installs some applications, games and
the OS itself takes up some capacity. This is also one reason why
the capacity that can be used for storage is less than the nominal
figure.
If the tablet can't work properly or does not respond for long time,
please press the reset button with a needle/clip or something like
that to reset.
44
11. Specification
Dimension
ca. 190 x 117.5 x 9 mm
7 inch, G + G capacitive 5 point touch-screen;
Display
resolution:1024 x 600 pixel
PC connection High speed USB 2.0
CPU
RAM
Memory

Configuration

Micro SD/
SDHC
(TF) card
OS
Access Network WI-FI
Internal
Power
DC output
max.earphone
output
MP3 bit rate
WMA bit rate
Audio
Frequency
response
SNR
Distortion
degree
MP1, MP2, MP3, WMA, WAV, OGG, OGA, APE,
Music Formats
FLAC, AAC, M4A, 3GPP, etc.
MPEG-1, MPEG-2, MPEG-4, H.263, H.264, AVS,
Video Formats VC-1, RV, VP6/VP8, Sorenson Spark, MVC
1920 x 1080P 60FPS, etc.
Image Formats JPG,JPEG, BMP, GIF, PNG, JFIF, etc.
Environment -5 to 40 °C
Temperature
Language multi-languages supported
OS Supported from WindowsXP/Linux2.4/MAC OS 10.4
All trademarks, registered trademarks and logos are the property of
their respective owners. We do not guarantee any data with respect to
their content, completeness or up-to-dateness
RK3066, ARM Cortex A9 Dual
Core bis zu 1,5 GHz
1 GB DDR III
8 GB (internal)
up to 64 GB (optional)
Android 4.1
IEEE802.11b/g/n
Lithium battery 3600 mAh
DC 5V/2A
(L) 7mW + (R9 7mW (32 ohm)
32 K bps – 320 K bps
16 K bps –320 K bps
20 Hz to 20 KHz +/- 3 dB
≥ 85 dB
< 0.6 %
45
