2 2 . . 3 3 F F r r o o n n t t v v i i e e w w
Link/Activity LED 3 24
-
Link/Activity LED 1 2 -
Status LED
Power LED
2 2 . . 4 4 L L E E D D
L L E E D D : :
Power
Link / Activity 1-2
Link / Activity 3-24
Status LED
Weidmüller t
24V/30mA
~
IE-SW22/2SC
green
red
green
green flashes
yellow
yellow flashes
green
green flashes
yellow
yellow flashes
green
red
Fibre optic interface
Fault relay
Fibre optic interface
power connection
valid power supply
invalid power supply
100 Mbit/s Link
100 Mbit/s Link traffic
10 Mbit/s Link
10 Mbit/s Link traffic
100 Mbit/s Link
100 Mbit/s Link traffic
10 Mbit/s Link
10 Mbit/s Link traffic
no problem
fault description
