XSStick ® W21
Quick Start Guide
1
Insert your microSD-
and your SIM Card
1. Insert the 2. Pull out the 3. Insert the SIM card and
microSD card, SIM card tray Push in the SIM card tray *
optional
4. To remove the cards proceed similarly.
* SIM card tray must be pushed in completely in the
equipment!
2
TM
Windows 7, Vista & XP
On connecting the XSStick ® W21 to the computer, you will
®
find the XSStick W21 as a drive under „My Computer".
Open this drive using e.g. Windows Explorer and start the
application "XSManagerinstallation.exe".
Then follow the instructions of the installation wizard.
TM
MAC OS X 10.5 or higher
A window with the disk image XSManager.dmg will open
automatically after connecting the XSStick
computer.
A virtual drive is opened by double-clicking this file. Double-
click the XSManager symbol to start the installation.
Then follow the instructions of the installation wizard.
3
The XSManager starts automatically after the installation has
been completed successfully.
You can use it to control all functions of the XSStick
When requested, enter the PIN of your SIM card and confirm with
OK.
These features can be started by pressing one of the following
buttons:
Connect:
SMS:
Statistics:
Web:
Settings:
4
Free Memory of your
The XSStick ® W21
microSD cards of up to 32 GB.
This option gives you the freedom of flexible, mobile data storage,
all in one device.
Please use the standard function of your operating system to
format a storage device for initial setup. This has to be done
only once.
Afterwards the memory of your XSStick
like an usual USB flash drive.
® W21 to the
Enter your PIN
® W21.
Function of the XSManager
Connect to the Internet.
Send or read short messages.
View details of the current connection.
Opens your default web browser.
Opens a dialog to configure your
XSStick ® W21.
®
XSStick W21
comprises a microSD card slot and it supports
® W21 can be accessed
5
Safety information
To protect yourself and the device from damage, please
observe the following when using and handling the
XSStick ® W21:
The XSStick ® W21 is designed solely for use in dry heated
rooms.
It must be kept away from fire and flames!
Do not use the XSStick ® W21 in areas with potentially
explosive atmospheres.
Prevent the device from exposure to direct sunlight or heat.
The device must not come into contact with liquid as this
could result in electric shock, short-circuiting or total
destruction of the device or worse.
Do not open the housing of the XSStick
cause a hazard to the user or damage the device.
With abusive and inappropriate treatment, use of force and
with interferences, which were not made by our authorized
service address, expires the warranty claim.
Disposal information
The European directive which became effective on February
13th 2003 and which was implemented in the Federal Republic
of Germany on August 18th 2005 for the prevention of
electronic and electrical waste has led to a considerable
change in the handling of electrical devices at the end
of their useful lives. The fundamental reason for this directive
is the prevention of electronic and electrical waste. This
includes waste management strategies that focus on reuse,
recycling, reconditioning or other forms of recycling of such
waste to reduce waste materials.
The use of the symbol ( ) indicates that this product may
not be treated as household waste. You are respon-
sible for disposing of all your electrical and electronic waste
correctly in the appropriate disposal service e.g. recycling
ground. . By ensuring this product is disposed of correctly,
you will help prevent potential negative consequences for the
natural resources, environment and human health which could
otherwise be caused by inappropriate waste handling of this
product. For more detailed information about recycling of
electronic and electrical waste, please contact your local city
office, your household waste disposal service, the shop where
you purchased the product or the product manufacturer.
©
4G Systems GmbH & Co. KG, Barmbeker Straße 2, 22303 Hamburg, Germany
www.4g-systems.com
® W21. This could
P/N: 4602.000047.00
