Troubleshooting

Q1: I typed http://192.168.10.1 in my Internet Browser's Address Bar, but an error
message says "The page cannot be displayed." How can I get into the
TEW-652BRP's web configuration page?
A1: First, check your hardware settings again by following the instructions in
Section 2. Second, make sure the LAN and WLAN lights are lit. Third, make sure
your TCP/IP settings are set to Obtain an IP address automatically (see the
steps below). Fourth, press on the factory reset button for 15 seconds.
1. Go into the Control Panel, click
Network and Internet, click Network
and Sharing Center, click Manage
Network Connections and then right-
click the Local Area Connection icon
and then click Properties.
Windows XP/2000
1. Go into the Control Panel, double-click
the Network Connections icon and
then right-click the Local Area
Connection icon and then click
Properties.
2. Click Internet Protocol Version
4(TCP/IPv4) and then click Properties.
Then click on Obtain an IP address
automatically.
2. Click Internet Protocol (TCP/IP) and
then click Properties. Then click on
Obtain an IP address automatically.
6
