Operation
2. If the receiver is not bound to this transmitter, the receiver LED will light up red. Push the BIND-button on
top of the receiver, the LED will turn to green.
3. The biding is succesfull, when the BIND-LED turn into solid green.
Bind-LED
Note:
1. During Frequency Pin Setup, make sure that Tx and Rx is one meter away, and around 10 meters there
is no similar (2.4 GHz) device.
2. Once success, no need to process the Binding again for that receiver.
3. If fail in Setup (BIND-LED still lights red), please try again patiently.

Operating the remote control

• Run your car never with low transmitter or receiver batteries.
• If the low battery alarm on the transmitter starts, stop running your model and change or recharge bat-
teries!
• Never forget switch off the radio after running your vehicle , otherwise the batteries do not last long.
• Turn on the transmitter first, then the vehicle.
• After driving first turn off the vehicle, then the transmitter.
• For optimal use first check the steering and throttle trim positions.

Function Menu

Voltage
Model name
Timer
Steering trim
Throttle trim

AUX Channel function (CH3)

The AUX-Channel is designed purely as a control channel and is not adjustable. The connected servo makes
a movement of 90 °.
With the switch in position „AUX", the servo rotates clockwise, in „OFF" position counterclockwise.

End Point Adjustment (EPA)

Use this when performing left and right steering angle adjustments, throttle high side/brake side ope-
ration amount adjustment, and channel 3 servo up side/down side operation amount adjustment during
XciteRC 3i LCD FHSS Pro-Spec 2.4 GHz
Bind-button
Steering
Dual Rate
Throttle Hold
Modulation
Main menu
Submenu
EN
25
