Usage
1.
Connect the audio/video cable to input AV1 or AV2.
2.
Connect the 12V rechargeable battery or a 12V power supply with the TFT test
monitor.
3.
Turn the test monitor on by switching the on/off switch.
4.
Use the
(-) or
5.
Press the MODE button. Each time you press the button the On-Screen-Menu
changes to the nest setting:
Volume -> Contrast -> Brightness -> Colour –Mute-> Tint (NTSC only)->Mirror
Use the
6.
To return to factory settings please proceed as follows:
•
Use the on/off switch (at the side) to turn the test monitor off.
•
Press the button MODE and simultaneously
again by using the on/off switch (at the side).
•
Press the button MODE again. Now you turn the on/off switch again to
turn the monitor off and on again.
7.
The monitor can be turned on and off by the on/off switch. You do not need to
disconnect power.
Attention: The setting TINT is only available for NTSC mode.
Technical data
Display
Anzeige
Pixel number
Picture size
Pixel size
System
Viewing angle
Reaction time
Input signal
Power supply
Operating temperature
Storage temperature
Power consumption
Size
Weight
(+) buttons to select video input 1 or 2.
(-) or
(+) buttons to select the desired value (0-100).
TV8165
TFT colour LCD
960x234
113,28 x 84,708
0,118 (H) x 0,362 (V)
NTSC/PAL
Left/Right: 90°
Top/Down 40°
Tr=15ms, Tf=20ms
1Vs-s / Analog VGA / Composite 75Ohm
DC12V +/- 10%
0°C bis +60°C
-15°C bis +80°C
7,0W
160 x 133 x 37 mm
475g
8
. Turn the test monitor on
