Instructions for installation and use

13. Technical data

Ambient conditions

Storage temperature:
Ambient temperature:
Relative humidity:
Sauna control unit
Dimensions:
Switched voltage / three-phase 3N:
Frequency:
Contact rating/heater:
Switched current per phase/heater:
Rated voltage:
Protection type (protected against jets of water):
Connection to the mains supply as fixed wiring (fixed connection)
Light
Contact rating:
Fuse:
Setting ranges
Temperature:
Thermal safety
Heater sensor with excess temperature fuse (139 °C shut-off temperature)
Adjustable automatic heating period (6 h, 12 h, 18 h, 24 h)*
Optional single-sensor mode or two-sensor mode
Connection cables
Power supply cable:
Heater supply cable (temperature-resistant up to 150 °C): min 2.5 mm²
Sensor wires (temperature-resistant up to 150 °C):
Light wire:
* EN 60335-2-53 specifies a heating time limitation of 6 h for saunas for private
use. For saunas in hotels, apartment blocks and similar locations, a maximum
heating period limit of 12 hours is permissible. Extending the heating period
limit to 18 hours or 24 hours is only permitted in public saunas.
WORLD OF WELLNESS
p. 30/30
-25 °C to +70 °C
-10 °C to +40 °C
max. 95 %
307 x 175 x 57 mm
400 V AC
50 Hz
3 x 3.5 kW
16 A
230 V
IPX4
100 W
1A T
30 °C to 110 °C
min. 5 x 2.5 mm²
min 0.5 mm²
min. 1.5 mm²
