I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
Video Conferencing Shelf
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
PAC715
Werbung
Inhaltszusammenfassung für CHIEF PAC715
- Seite 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation Video Conferencing Shelf Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description PAC715...
-
Seite 2: Installation Instructions
A WARNING alerts you to the possibility of installer’s responsibility to make sure the combined weight of serious injury or death if you do not follow the instructions. all equipment and accessories mounted on the PAC715 does not exceed 10 lbs (4.54 kg). DIMENSIONS 228.6... - Seite 3 Installation Instructions PAC715 LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
-
Seite 4: Tools Required For Installation
PAC715 Installation Instructions TOOLS REQUIRED FOR INSTALLATION 5/32" 1/4" PARTS C (4) B (2) 1/4-20" 1/4-20 x 3/4" A (1) [Video conferencing shelf] D (1) [medium faceplate adapter]... - Seite 5 (top installation) (bottom installation) Figure 2 Attach to Medium Faceplate NOTE: The PAC715 may only be mounted above the display when mounting to a medium faceplate. large (B) x 2 Use two 1/4-20" lock nuts (C) to secure medium faceplate faceplate adapter (D) to top or bottom of medium faceplate.
-
Seite 6: Camera Mounting
It is the installer’s responsibility to make sure the combined weight of all equipment and accessories mounted on the PAC715 does not exceed 10 lbs (4.54 kg). Mounting options will vary depending on the type of camera being mounted. - Seite 7 Installation Instructions PAC715...
- Seite 8 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 F +31 (0)40 2668615 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
