15. Ansteuerung über RS232 / RS485 Port
Baudrate=9600 Data / Bits=8 / No Parity / Stop Bits=1
On the player there is one RS485 port
RS485 format:"9600,8,N,1", Baudrate=9600,8 bit data, no parity,1 stop bit.
Format as follow.
"@0:2" or "@10:1",@ is the mark of address ,after #,there is one or two digit, this is the
address , after the colon, there is one or two digit, this is the play key No, the end mark
is the hex 0x0d or $
We also can input the command, such as " @0:OK$" or "@0:NEXT$", @00:5$

Command List

OK Enter key
UP Direction key, up
REV Reverse play
FWD Fast forward play
REP Repeat play
MUTE Mute key
VOL+ Volume up
VOL- Volume down
STOP Stop Key
PREV Previous key
NEXT Next key
ENTER Confirm key
LEFT Left key
DOWN Right key.
SYNC Trigger this key then go to the start of the file.
POWER Power on/off key
AUDIO Change the audio channel
PAUSE Pause key
RIGHT Right key
FMS- Film & Medien Service, 81549 München
@0:OK$
@0:UP$
@0:REV$
@0:FWD$
@0:REP$
@0:MUTE$
@0:VOL+$
@0:VOL-$
@0:STOP$
@0:PREV$
@0:NEXT$
@0:ENTER$
@0:LEFT$
@0:DOWN$
@0:SYNC$
@0:POWER$
@0:AUDIO$
@0:PAUSE$
@0:RIGHT$
Stand 22.04.2015 Seite 18
