Environmental Characteristics
Operation
Storage
HINWEIS
The environment is under normal atmosphere pressure.
While the environment temperature is above 65°C, the humidity will be allowed in below 50%RH.
Optical Characteristics
Transparency
Haze
Electrical Characteristics
Loop Resistance
Linearity
Chattering
Insulation
Endurance
Note: Loop Resistance X = short RT and RL , short LT and LL , measure the resistance between RT and LT Loop Resistance
Y = short RT and LT , short RL and LL ,measure the resistance between RT and RL
Mechanical Characteristics
Operating Force
Impact
Static Load
Hardness
Peeling
Bending
Temperature
-10°C ~ +60°C
-40°C ~ +80°C
≧80% (measured by BYK-Gardner)
Clear Finish ≦5% ± 2%
Antiglare Finish ≦10% ± 2%
X:20~500Ω, Y:20~500Ω
X≦1.0%, Y≦1.0%
≦15ms
≧20MΩ/25V(DC)
No acting damage at DC50V/60sec.
Specification
Stylus=R0.8
13.0ψDIA. Steel Ball/9g
Height=30cm
500g within 30 cm² area for 30sec
3H pencil, pressure 1N/45°
800g by vertical 90°
135°10 times left & right
-

-
Humidity (Non Condensing)
20%RH ~ 85%RH
10%RH ~ 90%RH
Condition
≦50g
1 time, no damage
[Impact at center area]
≧3H
